A bench drill is an essential tool for anyone working with wood, metal or plastic who wants precise drill holes every time. The machine offers stability, consistency and the ability to drill into materials that are difficult to handle with a hand drill. However, with the wide range of models on the market – from compact hobby versions to powerful machines for professional use – it can be a challenge to find the right solution.
In this article, you’ll get a comprehensive overview of what to look for when choosing a bench drill, as well as an introduction to the most common types, features and manufacturers.
The article presents a wide selection of bench drills that cover different needs and price ranges. The aim is to provide an overview of key features, technical specifications and areas of application so that you can more easily assess which type of machine suits your workshop. The product information is based on publicly available descriptions from manufacturers and retailers and is summarised to provide a neutral and informative overview.
Factors to consider when buying a bench drill
When choosing a bench drill, it’s about finding the right balance between power, precision and functionality. Here are some of the most important factors you should consider.
1. Motor power and drilling capacity
The motor power determines how powerfully the machine can drill into different materials. For light woodwork, a smaller motor may be sufficient, while metalworking requires a more powerful model. The drilling capacity – that is, how large the hole the machine can drill – typically ranges from 13 mm to over 20 mm.
2. Speed settings
A bench drill with variable speed offers more flexibility, as different materials require different drilling speeds. Many models have stepwise adjustment via pulleys, while newer machines offer electronic control for more precise regulation.
3. Table and adjustment options
A stable and adjustable drill table is important for precise results. The table should be tiltable and height-adjustable so that you can drill at different angles and material thicknesses. Some models also have built-in scales and clamps to help with accurate positioning.
4. Column height and stroke length
The column height determines how large workpieces you can handle, while the stroke length indicates how deep the drill can move. If you often work with larger workpieces, you should choose a machine with extra height and a longer stroke.
5. Safety and ease of use
A good bench drill should have a safety cover, an emergency stop switch and the ability to secure the workpiece. Ergonomic handles and clearly visible controls make the work more comfortable and safer.
6. Price and quality
The price depends on motor power, build quality and additional features. For hobby use, a compact model may be sufficient, while professional users should invest in a machine with higher precision and longer service life.
Products in focus
The JET Bench Drill 210 Z is a compact and stable machine designed for precision drilling in various materials. It comes with a drill chuck (0.5–13 mm) and a 75 mm machine vice, making it ready for immediate use.
The machine is equipped with a safety device combined with the drill chuck drive and a front-mounted emergency stop switch to increase safety during operation. The speed change is made via a belt drive, allowing the drilling speed to be adjusted to the material.
The drill table has two parallel 12 mm holes, and the spindle has a stroke of 53 mm. With a spindle mount of B16 and a maximum drilling diameter of 10 mm, the machine is suitable for precision work on smaller workpieces.
The motor operates at 230V and delivers 0.19 kW. The machine has five speeds from 600 to 2600 revolutions per minute, providing flexibility for various drilling tasks. The compact size and weight of 32 kg make it easy to place on a workbench.
The JET 210 Z is designed for reliability and ease of use, making it suitable for both hobby workshops and lighter professional applications.
- Five speeds: Adjustable drilling speed from 600 to 2600 rpm via belt drive.
- Safe operation: Equipped with emergency stop switch and safety device on the drill chuck.
- Compact design: Fits well on workbenches in smaller workshops.
- Stable construction: Weight of 32 kg ensures good stability during drilling.
- Delivered ready for use: Includes drill chuck (0.5–13 mm) and 75 mm machine vice.
Pros and cons
- Stable and compact construction
- Multiple speed levels via belt drive
- Built-in emergency stop switch for increased safety
- Comes with relevant accessories
- Limited drilling capacity of max. 10 mm
- Manual speed adjustment requires belt change
Pros and cons
Pros
- Stable and compact construction
- Multiple speed levels via belt drive
- Built-in emergency stop switch for increased safety
- Comes with relevant accessories
Cons
- Limited drilling capacity of max. 10 mm
- Manual speed adjustment requires belt change
Pros
- Stable and compact construction
- Multiple speed levels via belt drive
- Built-in emergency stop switch for increased safety
- Comes with relevant accessories
Cons
- Limited drilling capacity of max. 10 mm
- Manual speed adjustment requires belt change
Specifications
- Model: 210 Z
- Manufacturer: JET
- Motor voltage: 230 V
- Motor power: 0.19 kW
- Spindle mount: B16
- Maximum drilling diameter: Ø10 mm
- Distance spindle-column: 105 mm
- Spindle stroke: 53 mm
- Speeds: 5 levels (600–2600 rpm)
- Drill table: 2 parallel holes of 12 mm
- Slots (number/size): T12
- Weight: 32 kg
- Dimensions (L×W×H): 600 × 420 × 240 mm
- Included accessories: Drill chuck 0.5–13 mm, machine vice 75 mm
The Axminster Workshop AW315PD is a bench drill made of cast iron and machined steel, offering high stability and reducing vibrations during operation. It is equipped with a quiet 550 W induction motor that drives the spindle via a belt drive with 12 different speeds ranging from 210 to 2,580 revolutions per minute.
The machine features a keyless chuck with a capacity of 1 to 16 mm, making bit changes easy without tools. The drilling depth can be precisely adjusted, and the feed lever is fitted with soft grips for better control.
The table height is adjusted via a rack and pinion system, and the entire table can be swung away so that the base of the machine can be used to support larger workpieces. An adjustable safety guard and a front-mounted NVR switch contribute to safe operation.
The AW315PD is suitable for precision drilling in wood, plastic, and metals and is a practical choice for users seeking a stable and reliable machine for workshop use.
- Cast iron construction: Provides stability and reduces vibration during drilling.
- 550 W induction motor: Ensures quiet and reliable operation.
- 12 speeds: From 210 to 2,580 rpm for various materials and drilling tasks.
- Keyless chuck: Quick and easy bit changes from 1 to 16 mm.
- Adjustable table: Height and angle can be adjusted via a rack and pinion system.
Pros and cons
- Robust and vibration-damping cast iron construction
- Quiet induction motor with 12 speeds
- Easy adjustment of table height and drilling depth
- Keyless chuck for quick bit changes
- Suitable for precision work in multiple materials
- Not compatible with Morse tapers
- Relatively heavy 37 kg construction may require fixed placement
Pros and cons
Pros
- Robust and vibration-damping cast iron construction
- Quiet induction motor with 12 speeds
- Easy adjustment of table height and drilling depth
- Keyless chuck for quick bit changes
- Suitable for precision work in multiple materials
Cons
- Not compatible with Morse tapers
- Relatively heavy 37 kg construction may require fixed placement
Pros
- Robust and vibration-damping cast iron construction
- Quiet induction motor with 12 speeds
- Easy adjustment of table height and drilling depth
- Keyless chuck for quick bit changes
- Suitable for precision work in multiple materials
Cons
- Not compatible with Morse tapers
- Relatively heavy 37 kg construction may require fixed placement
Specifications
- Model: AW315PD
- Item number (SKU): AX107691
- Voltage: 230 V
- Power: 550 W
- Speeds: 12 steps (210–2,580 rpm)
- Chuck capacity: 1–16 mm
- Chuck type: Keyless
- Drilling stroke: 60 mm
- Column diameter: 60 mm
- Max. distance chuck–spindle: 430 mm
- Max. distance chuck–table: 315 mm
- Max. drilling in mild steel: 16 mm
- Table size: 198 × 198 mm
- Table tilt: 45° – 0° – 45°
- Throat depth: 127 mm
- Dimensions (L × W × H): 520 × 260 × 840 mm
- Weight: 37 kg
- Plug type: UK 3-pin plug
- User level: Home workshop
The PROMAC Bench Drill 370ELB is a stationary drill designed for precision drilling in metal and other hard materials. The machine is powered by a 230 V motor with an output of 0.75 kW and has a single speed that is adjusted via a V-belt.
It is equipped with a 16 mm self-tightening chuck, a protective shield, and an emergency stop switch for increased safety during operation. The worktable has adjustable cross grooves that provide flexibility when securing workpieces, and a safety system prevents automatic restart after a power failure.
An integrated LED work light provides targeted illumination of the drilling area, improving precision when working on detailed pieces. The machine’s construction and its weight of 74 kg contribute to stable operation with minimal vibration.
With a speed range of 290 to 2300 revolutions per minute and a drilling depth of up to 80 mm, the 370ELB is suitable for a wide range of drilling tasks in the workshop.
- Single-speed motor: Simple and reliable design with V-belt adjustment.
- Self-tightening chuck: Allows quick drill bit changes without a key.
- Safety features: Protective shield, emergency stop, and system against automatic restart.
- LED work light: Provides precise illumination of the drilling area.
- Stable construction: 74 kg machine weight reduces vibrations during operation.
Pros and cons
- Robust and stable construction
- Easy operation with V-belt adjustment
- Integrated LED lighting for better work illumination
- Safety system against automatic start
- Suitable for precision drilling in metal
- Only a single-speed motor may limit flexibility with certain materials
- Relatively heavy machine, requires a fixed place on the workbench
Pros and cons
Pros
- Robust and stable construction
- Easy operation with V-belt adjustment
- Integrated LED lighting for better work illumination
- Safety system against automatic start
- Suitable for precision drilling in metal
Cons
- Only a single-speed motor may limit flexibility with certain materials
- Relatively heavy machine, requires a fixed place on the workbench
Pros
- Robust and stable construction
- Easy operation with V-belt adjustment
- Integrated LED lighting for better work illumination
- Safety system against automatic start
- Suitable for precision drilling in metal
Cons
- Only a single-speed motor may limit flexibility with certain materials
- Relatively heavy machine, requires a fixed place on the workbench
Specifications
- Motor voltage: 230 V
- Motor power: 0.75 kW
- Spindle taper: MK-2
- Drilling capacity in steel: Ø16 mm
- Drilling depth: 80 mm
- Number of speeds: 12 steps
- Speed range: 290–2300 min⁻¹
- Table load: 40 kg
- T-slot: 12 mm
- Weight: 74 kg
- Model number / SKU: 370ELB
The Holzmann ZS40HS 400V is a stationary bench drill designed for precision work in metal and wood. It is equipped with an extra-large cast iron work table that is height adjustable and can rotate 360 degrees around the central axis. The table features 14 mm T-slots that allow secure fastening of workpieces and accessories during operation.
The machine's gear head can be adjusted in height and tilted, providing flexibility when drilling at various angles. The gears are oil-bath lubricated to ensure smooth and quiet operation as well as long service life. The powerful motor delivers continuous drilling power, making the machine suitable for demanding tasks.
For increased safety, the spindle guard is height adjustable and equipped with a microswitch. The machine comes with a drill chuck (16 mm), reducers (MT4/3 and MT3/2), wedge and drawbar, making it ready for immediate use.
With a maximum height of over two metres and a weight of 320 kg, the ZS40HS 400V is a stable and solid machine built for precision and durability in workshop environments.
- XL work table: Large cast iron table (550 × 480 mm) with 360° rotation and T-slots.
- Adjustable gear head: Can be tilted and height adjusted for flexible drilling.
- Oil-bath gearbox: Ensures smooth operation and reduced wear.
- Powerful motor: Delivers continuous drilling power for demanding tasks.
- Safety feature: Spindle guard with microswitch for increased safety.
Pros and cons
- Solid cast iron construction
- Large work surface with flexible adjustment
- Oil-bath gearbox for smooth operation
- Comes with necessary accessories
- Suitable for large and heavy workpieces
- High weight of 320 kg requires a fixed location
- Requires 400V power supply
- Not suitable for small hobby workshops with limited space
Pros and cons
Pros
- Solid cast iron construction
- Large work surface with flexible adjustment
- Oil-bath gearbox for smooth operation
- Comes with necessary accessories
- Suitable for large and heavy workpieces
Cons
- High weight of 320 kg requires a fixed location
- Requires 400V power supply
- Not suitable for small hobby workshops with limited space
Pros
- Solid cast iron construction
- Large work surface with flexible adjustment
- Oil-bath gearbox for smooth operation
- Comes with necessary accessories
- Suitable for large and heavy workpieces
Cons
- High weight of 320 kg requires a fixed location
- Requires 400V power supply
- Not suitable for small hobby workshops with limited space
Specifications
- Model: ZS40HS 400V
- Manufacturer: Holzmann
- Motor power (S6/S1): 1500/1100 W
- Voltage: 400 V
- Cable length: 2.5 m
- Table size: 550 × 480 mm
- Maximum height: 2120 mm
- Spindle travel: 120 mm
- Distance spindle–base: 1250 mm
- Maximum distance spindle–table: 790 mm
- Weight: 320 kg
- Included accessories: Drill chuck 16 mm, reducer MT4/3 and MT3/2, wedge, drawbar
The Scheppach DP16VLS is a stationary bench drill designed for precision drilling in various materials such as metal and wood. The integrated positioning laser helps to mark the drilling point accurately, making work more efficient and precise.
The machine is powered by a 500 W motor running on 230 volts and offers five different speeds from 600 to 2600 revolutions per minute. This allows the user to adjust the speed to the material and drilling task.
The chuck ranges from 3 to 16 mm, and the maximum drilling size is 16 mm. The worktable measures 160 x 168 mm, and the column diameter is 46 mm, providing stability during drilling. The spindle travel is 46 mm, and the machine has overall dimensions of 460 x 255 x 630 mm.
Weighing 17 kg, the DP16VLS is light enough to be moved when needed but still robust enough to remain stable during use. A vice is included as standard, increasing flexibility when clamping workpieces.
- Positioning laser: Ensures precise marking of the drilling point.
- Flexible speed control: Five speeds from 600 to 2600 rpm.
- Powerful motor: 500 W motor for versatile drilling tasks.
- Stable construction: 46 mm column diameter and solid base for safe operation.
- Included vice: Makes it easier to clamp workpieces during drilling.
Pros and cons
- Integrated laser for precise drilling
- Multiple speed levels for different materials
- Compact and stable construction
- Included vice increases user-friendliness
- Limited spindle travel of 46 mm can be a challenge for deeper drilling
- Not intended for heavy industrial use
Pros and cons
Pros
- Integrated laser for precise drilling
- Multiple speed levels for different materials
- Compact and stable construction
- Included vice increases user-friendliness
Cons
- Limited spindle travel of 46 mm can be a challenge for deeper drilling
- Not intended for heavy industrial use
Pros
- Integrated laser for precise drilling
- Multiple speed levels for different materials
- Compact and stable construction
- Included vice increases user-friendliness
Cons
- Limited spindle travel of 46 mm can be a challenge for deeper drilling
- Not intended for heavy industrial use
Specifications
- Motor power: 500 W – 230 V
- Revolutions/min: 1450
- Speeds: 600 / 900 / 1300 / 1800 / 2600 rpm
- Chuck: 3–16 mm
- Max. drilling size: 16 mm
- Worktable: 160 × 168 mm
- Column diameter: 46 mm
- Spindle travel: 46 mm
- Dimensions (L × W × H): 460 × 255 × 630 mm
- Weight: 17 kg
- Included accessories: Vice
- Item number (SKU): 5906810901
The Optimum OPTIdrill DQ 14 is a bench drill designed for precision drilling in metal and other materials. The machine is made of die-cast aluminium and equipped with a soft-grip handle, allowing for stable and comfortable operation.
The drill table can be tilted ±45° and rotated 360°, providing flexibility for various drilling tasks. A clearly readable depth scale and a separate emergency stop switch contribute to safe and controlled operation.
The spindle is equipped with precision ball bearings and offers a runout accuracy of less than 0.03 mm, making the machine suitable for tasks where precision is crucial. The quick-release chuck and GATES quality belt ensure efficient power transmission.
With a motor power of 0.35 kW and a speed range of 700 to 2500 revolutions per minute, distributed over five stages, the machine can be adapted to different materials and drilling types. The large base plate with T-slots ensures stability during operation.
- Precision drilling: Runout accuracy below 0.03 mm for high precision.
- Flexible drill table: Can be tilted ±45° and rotated 360° for versatile use.
- Solid construction: Die-cast aluminium with soft-grip handle for stability and comfort.
- Efficient power transmission: Equipped with GATES quality belt and precision ball bearings.
- Safe operation: Separate emergency stop switch and 24 V DC safety low voltage.
Pros and cons
- High precision and stable operation
- Adjustable and rotatable drill table
- Robust aluminium construction
- Compact size, suitable for workbenches
- Safety features such as emergency stop and low voltage
- Limited drilling capacity compared to larger pillar drills
- Requires manual speed adjustment via pulleys
Pros and cons
Pros
- High precision and stable operation
- Adjustable and rotatable drill table
- Robust aluminium construction
- Compact size, suitable for workbenches
- Safety features such as emergency stop and low voltage
Cons
- Limited drilling capacity compared to larger pillar drills
- Requires manual speed adjustment via pulleys
Pros
- High precision and stable operation
- Adjustable and rotatable drill table
- Robust aluminium construction
- Compact size, suitable for workbenches
- Safety features such as emergency stop and low voltage
Cons
- Limited drilling capacity compared to larger pillar drills
- Requires manual speed adjustment via pulleys
Specifications
- Manufacturer: Optimum
- Model: OPTIdrill DQ 14
- SKU: SM-3191040
- Column diameter: 46 mm
- Length: approx. 472 mm
- Width/Depth: approx. 283 mm
- Height: approx. 634 mm
- Weight: approx. 18.5 kg
- Drilling capacity in steel (S235JR): 13 mm
- Continuous drilling capacity in steel (S235JR): 12 mm
- Drill table size: 170 × 170 mm
- T-slot size: 14 mm (2 pieces, diagonal type)
- Drill table rotation: 360°
- Drill table angle: ±45°
- Max. distance spindle – drill table: 250 mm
- Max. distance spindle – machine base: 340 mm
- Drive power: 0.35 kW
- Supply voltage: 230 V
- Mains frequency: 50 Hz
- Speed range: 700–2500 min⁻¹ (5 stages)
- Spindle stroke: 52 mm
- Spindle mount: B16
- Throat depth: 104 mm
The Proxxon TBH is a bench drill designed for precision work where stability and accuracy are crucial. The machine is powered by a high-performance DC motor with a long service life, ensuring smooth operation and constant torque under load.
The height can be easily adjusted via a rack-and-pinion mechanism with a hand crank, allowing precise control of the drilling position. The spindle drive is equipped with triple pulleys offering three speed levels – 1080, 2400, and 4500 revolutions per minute – allowing the user to adjust the speed to the material.
The machine features a drilling depth scale with an adjustable stop, and the drill spindle is mounted in precision ball bearings to ensure stable operation. The spindle head has a 1/2" thread and fits an industrial-quality RÖHM geared chuck. In addition, the spindle can be equipped with collets (No. 28200) for additional precision work.
With a column of 45 x 500 mm, a worktable of 200 x 200 mm, and a weight of about 10 kg, the TBH is both stable and compact, making it ideal for smaller workshops and precision work in metal and plastic.
- DC motor: Durable motor with stable operation and low vibration.
- Stepwise speed control: Three speed levels (1080, 2400, and 4500 rpm) for different materials.
- Precise height adjustment: Rack and pinion with hand crank for easy and accurate adjustment.
- Stable construction: Column and table in robust design for precision drilling.
- Compatibility: Suitable for RÖHM geared chuck and collets No. 28200.
Pros and cons
- Precise and stable operation with ball bearings in the spindle
- Long service life thanks to DC motor
- Easy height adjustment with hand crank
- Option to use collets for precision drilling
- Compact and solid construction
- Limited drilling capacity compared to larger pillar drills
- Requires manual belt change to adjust speed
Pros and cons
Pros
- Precise and stable operation with ball bearings in the spindle
- Long service life thanks to DC motor
- Easy height adjustment with hand crank
- Option to use collets for precision drilling
- Compact and solid construction
Cons
- Limited drilling capacity compared to larger pillar drills
- Requires manual belt change to adjust speed
Pros
- Precise and stable operation with ball bearings in the spindle
- Long service life thanks to DC motor
- Easy height adjustment with hand crank
- Option to use collets for precision drilling
- Compact and solid construction
Cons
- Limited drilling capacity compared to larger pillar drills
- Requires manual belt change to adjust speed
Specifications
- Voltage: 220–240 V
- Speeds: 1080 / 2400 / 4500 rpm
- Spindle travel: 63 mm
- Height adjustment: 70 mm via hand crank
- Throat depth: 120 mm
- Worktable surface: 200 × 200 mm
- Column: 45 × 500 mm
- Max. drilling capacity in steel: 10 mm
- Clamping range: up to 10 mm
- Weight: approx. 10 kg
- Compatible chuck: RÖHM geared chuck (1/2" thread)
- Option for collets: No. 28200
- SKU: ROL-28124
The Record DP58B Heavy Duty is a stationary bench drill made of steel and cast iron, ensuring stability and durability. It is equipped with a powerful induction motor that provides smooth operation and can handle both hardwood and metal parts.
The machine features a cast iron table with grooves that allow secure attachment of a vice. The table can be tilted up to 45 degrees, providing flexibility when drilling at angles. A rack and pinion system makes height adjustment of the table easy.
With 12 different speeds, the user can adjust the rotation speed to the material, making the machine suitable for many types of drilling work. The spindle sleeve is designed to minimise vibrations and ensure precision during operation.
The machine has a maximum chuck capacity of 16 mm, a weight of 55 kg and an overall height of 1050 mm, making it suitable for both professional users and hobbyists who want a stable and precise drill.
- 12 speeds: Allows precise adjustment for different materials.
- Cast iron table: Can be tilted up to 45° and has grooves for attaching a vice.
- Induction motor: Provides stable performance for drilling in wood and metal.
- Solid construction: Steel and cast iron reduce vibrations and increase precision.
- Ergonomic design: Handles and height adjustment are designed for easy operation.
Pros and cons
- Robust and vibration-damping construction
- Flexible speed control with 12 levels
- Suitable for metal and woodwork
- Cast iron table with angle adjustment
- Long service life thanks to induction motor
- Relatively heavy machine, requires a fixed location
- Requires manual belt change to adjust speed
Pros and cons
Pros
- Robust and vibration-damping construction
- Flexible speed control with 12 levels
- Suitable for metal and woodwork
- Cast iron table with angle adjustment
- Long service life thanks to induction motor
Cons
- Relatively heavy machine, requires a fixed location
- Requires manual belt change to adjust speed
Pros
- Robust and vibration-damping construction
- Flexible speed control with 12 levels
- Suitable for metal and woodwork
- Cast iron table with angle adjustment
- Long service life thanks to induction motor
Cons
- Relatively heavy machine, requires a fixed location
- Requires manual belt change to adjust speed
Specifications
- Model: DP58B Heavy Duty
- Manufacturer: Record
- Item number (SKU): RECDP58B-EP
- Voltage: 230V
- Motor power P1/P2: 0.6 kW / 0.37 kW
- Throat depth: 165 mm
- Drilling depth: 80 mm
- Chuck to table: 371 mm
- Chuck to base: 548 mm
- Chuck: 16 mm
- Speeds: 180, 250, 300, 400, 480, 580, 970, 1280, 1410, 1540, 2270, 2740 rpm
- Weight: 55 kg
- Dimensions: H1050 × W270 × D563 mm
The Rotwerk RB18 Vario is a bench drill designed for precision drilling in metal and other materials. It is equipped with a variable drive that allows the spindle speed to be adjusted steplessly without having to open or disassemble the machine.
The machine is powered by a 600 W motor and is designed to maintain torque across the entire speed range. This ensures a stable and consistent drilling process regardless of speed. The drive and construction are made in Germany, supporting the machine’s quality and durability.
The RB18 Vario has a drilling capacity of up to 18 mm in steel and a spindle mount of type MK2. It is equipped with a drill chuck that clamps from 1 to 16 mm and offers two speed ranges: 290–880 min⁻¹ and 880–2400 min⁻¹. The machine has a drilling depth of 50 mm and a throat depth of 115 mm.
With a column diameter of 60 mm, a column height of 600 mm, and an overall height of 765 mm, the RB18 Vario is a stable and compact machine weighing around 31 kg. It is suitable for both workshops and hobby spaces where precision and flexibility are important.
- Variable drive: Stepless adjustment of spindle speed without disassembling the machine.
- Stable torque: Maintains performance across the entire speed range.
- German manufacturing: Drive and construction produced in Germany.
- Powerful motor: 600 W motor for demanding drilling tasks.
- Precision drilling: Drilling capacity up to 18 mm in steel.
Pros and cons
- Stepless speed control via variable drive
- Stable and robust construction
- Maintains torque at low speed
- Suitable for both professional and hobby applications
- German drive for high quality
- Relatively high weight of approx. 31 kg can make it less mobile
- Limited drilling depth of 50 mm compared to larger pillar drills
Pros and cons
Pros
- Stepless speed control via variable drive
- Stable and robust construction
- Maintains torque at low speed
- Suitable for both professional and hobby applications
- German drive for high quality
Cons
- Relatively high weight of approx. 31 kg can make it less mobile
- Limited drilling depth of 50 mm compared to larger pillar drills
Pros
- Stepless speed control via variable drive
- Stable and robust construction
- Maintains torque at low speed
- Suitable for both professional and hobby applications
- German drive for high quality
Cons
- Relatively high weight of approx. 31 kg can make it less mobile
- Limited drilling depth of 50 mm compared to larger pillar drills
Specifications
- Model: RB18 Vario
- Manufacturer: Rotwerk
- Mains voltage: 230 V / 50 Hz
- Power: 600 W
- Drill chuck: 1–16 mm
- Spindle mount: MK2
- Drilling capacity in steel: 18 mm
- Speed range I: 290–880 min⁻¹
- Speed range II: 880–2400 min⁻¹
- Torque range I: 5.3–4.0 Nm
- Torque range II: 1.8–1.3 Nm
- Throat depth: 115 mm
- Drilling depth: 50 mm
- Column diameter: 60 mm
- Column height: 600 mm
- Overall height: 765 mm
- Weight: approx. 31 kg
- SKU: RB18VARIO
The Axminster Workshop AW285PD is a bench drill designed for smaller workshops and hobby applications where precision and stability are important. The machine is made of cast iron and machined steel, providing a solid base and reducing vibrations during operation.
It is powered by a 350 W induction motor that ensures smooth and quiet operation. The user can choose between five belt speeds from 600 to 2,500 revolutions per minute, allowing the speed to be adjusted for different materials and drilling tasks.
The machine is equipped with a keyless chuck that can hold drill bits from 1 to 13 mm, as well as a depth control that ensures consistent drilling holes. The table can be adjusted in height and tilted from 45° to 0° to 45°, providing flexibility for various work tasks.
A front-mounted NVR switch and an adjustable safety guard contribute to safe operation. The belt cover also has a safety switch that prevents accidental starting during speed changes. The combination of compact size and robust construction makes the AW285PD suitable for both beginners and experienced users who need a reliable drill for precision work.
- Solid construction: Cast iron and machined steel provide stability and reduce vibrations.
- Efficient motor: 350 W induction motor with smooth and quiet operation.
- Flexible speed control: Five belt speeds from 600 to 2,500 rpm.
- Keyless chuck: Allows quick change of drill bits between 1 and 13 mm.
- Adjustable table: The table can be raised, lowered and tilted to allow precise positioning.
- Safe operation: NVR switch and safety guard increase safety during use.
Pros and cons
- Robust and vibration-damping construction
- Smooth operation with induction motor
- Multiple speed levels for different materials
- Easy operation with keyless chuck
- Compact size, suitable for smaller workshops
- Not suitable for chiselling or very heavy drilling work
- UK 3-pin plug may require an adapter when used in Denmark
Pros and cons
Pros
- Robust and vibration-damping construction
- Smooth operation with induction motor
- Multiple speed levels for different materials
- Easy operation with keyless chuck
- Compact size, suitable for smaller workshops
Cons
- Not suitable for chiselling or very heavy drilling work
- UK 3-pin plug may require an adapter when used in Denmark
Pros
- Robust and vibration-damping construction
- Smooth operation with induction motor
- Multiple speed levels for different materials
- Easy operation with keyless chuck
- Compact size, suitable for smaller workshops
Cons
- Not suitable for chiselling or very heavy drilling work
- UK 3-pin plug may require an adapter when used in Denmark
Specifications
- Model: AW285PD
- Item number (SKU): AX107690
- Voltage: 230 V
- Power: 350 W
- Speeds: 5 levels (600–2,500 rpm)
- Chuck capacity: 1–13 mm
- Chuck type: Keyless
- Drilling stroke: 50 mm
- Column diameter: 46 mm
- Max. distance chuck–spindle: 380 mm
- Max. distance chuck–table: 285 mm
- Max. drilling in mild steel: 13 mm
- Table size: 165 × 165 mm
- Table tilt: 45° – 0° – 45°
- Throat depth: 105 mm
- Dimensions (L × W × H): 500 × 280 × 735 mm
- Weight: 26 kg
- Plug type: UK 3-pin
The PROMAC Bench Drill 371ELB is a stationary drill designed for precision work in metal and other hard materials. It is powered by a 400-volt motor with an output of 0.75 kW, ensuring stable operation and sufficient power for most drilling tasks in the workshop.
The machine features speed control via a V-belt and offers 12 different speed levels ranging from 290–2300 revolutions per minute. This allows the speed to be adjusted to different materials and drill diameters.
The drill chuck is self-tightening and can accommodate drill bits up to 16 mm in diameter. The worktable is equipped with adjustable cross grooves and can support up to 40 kg, providing flexibility when securing workpieces.
For increased safety, the machine is equipped with an emergency stop, a protective screen, and a system that prevents automatic restart after a power failure. An integrated LED lamp provides targeted illumination of the drilling area, allowing work to be carried out with high precision.
- Motor: 400 V, 0.75 kW with 12 speed levels via V-belt.
- Drilling capacity: Up to 16 mm in steel.
- Safety: Emergency stop, protective screen, and anti-restart system.
- Worktable: Adjustable cross grooves and load capacity up to 40 kg.
- Lighting: Built-in LED lamp for better visibility during work.
Pros and cons
- Stable and powerful motor for precision drilling
- Ability to control speed via V-belt
- Safety features such as emergency stop and protective screen
- LED work lamp for better visibility
- Solid construction with high weight for stability
- Requires a 400 V power supply, which may limit use in private workshops
- Manual speed adjustment via V-belt can take some time
Pros and cons
Pros
- Stable and powerful motor for precision drilling
- Ability to control speed via V-belt
- Safety features such as emergency stop and protective screen
- LED work lamp for better visibility
- Solid construction with high weight for stability
Cons
- Requires a 400 V power supply, which may limit use in private workshops
- Manual speed adjustment via V-belt can take some time
Pros
- Stable and powerful motor for precision drilling
- Ability to control speed via V-belt
- Safety features such as emergency stop and protective screen
- LED work lamp for better visibility
- Solid construction with high weight for stability
Cons
- Requires a 400 V power supply, which may limit use in private workshops
- Manual speed adjustment via V-belt can take some time
Specifications
- Motor voltage: 400 V
- Motor power: 0.75 kW
- Spindle taper: MK-2
- Drilling capacity in steel: Ø16 mm
- Drilling depth: 80 mm
- Number of speeds: 12
- Speed range: 290–2300 min⁻¹
- Table load: 40 kg
- T-slot: 12 mm
- Weight: 74 kg
- Model number: 371ELB
The Holzmann SB4116HM 230V is a bench drill designed with a focus on stability and accuracy. The machine features a solid, polished base with T-slots, providing a secure foundation during operation. The stainless steel column contributes to the rigidity and precision of the machine when drilling.
The motor is an aluminium motor with IP54 protection, offering a good balance between performance and durability. The worktable can be tilted from -45° to +45° and rotated 360° around its axis, allowing drilling at various angles and positions.
The machine comes with a self-tightening drill chuck (3–16 mm, B16), and the spindle is equipped with a protective cover for increased safety. The combination of adjustability, power, and precision makes it suitable for both metal and woodwork in smaller workshops.
With a maximum drilling capacity of 16 mm, 12 speed levels from 180 to 2740 revolutions per minute, and a maximum height of 1060 mm, the SB4116HM offers a flexible working platform for many types of drilling tasks.
- Powerful motor: 600 W (S1) / 900 W (S6) with IP54 protection.
- Adjustable worktable: Can be tilted from -45° to +45° and rotated 360°.
- Solid construction: Stainless steel column and polished base with T-slots.
- Flexible drilling capacity: Up to 16 mm drilling diameter and 12 speed levels.
- Safety: Spindle guard and stable base for precise work.
Pros and cons
- Stable and robust stainless steel construction
- Adjustable and rotatable worktable
- Powerful motor with IP54 protection
- Suitable for metal and woodwork
- Comes with self-tightening drill chuck
- Relatively high weight of 50 kg can make it less mobile
- Requires a fixed workspace and proper setup for optimal precision
Pros and cons
Pros
- Stable and robust stainless steel construction
- Adjustable and rotatable worktable
- Powerful motor with IP54 protection
- Suitable for metal and woodwork
- Comes with self-tightening drill chuck
Cons
- Relatively high weight of 50 kg can make it less mobile
- Requires a fixed workspace and proper setup for optimal precision
Pros
- Stable and robust stainless steel construction
- Adjustable and rotatable worktable
- Powerful motor with IP54 protection
- Suitable for metal and woodwork
- Comes with self-tightening drill chuck
Cons
- Relatively high weight of 50 kg can make it less mobile
- Requires a fixed workspace and proper setup for optimal precision
Specifications
- Model: SB4116HM 230V
- Motor power (S1/S6): 600 W / 900 W
- Voltage: 230 V
- Table size: 250 × 250 mm
- Maximum height: 1060 mm
- Distance from chuck to column: 170 mm
- Maximum drilling stroke: 80 mm
- Base plate: 270 × 450 mm
- Maximum drilling capacity: 16 mm
- Spindle speed: 12 levels, 180–2740 min⁻¹
- Distance from spindle to base plate: 695 mm
- Distance between spindle and table: 495 mm
- Net weight: 50 kg
- Package dimensions (L×W×H): 895 × 490 × 290 mm
- Scope of delivery: Self-tightening drill chuck 3–16 mm, B16
The Optimum OPTIdrill DQ 22 is a bench drill designed for precision work and stable operation. The machine is equipped with a separate emergency stop switch and a drilling depth limiter, which increases safety and allows repeated drilling operations with high accuracy.
The drill table is precisely machined and can be tilted by ±45° and rotated 360°, providing flexibility for various drilling tasks. The table has diagonally arranged T-slots and a surrounding coolant groove, making it suitable for metalworking.
The machine features a die-cast aluminium lever arm with a soft-grip handle, and the spindle is mounted with precision ball bearings to ensure a runout accuracy of less than 0.03 mm. The quick-release chuck and GATES quality belt contribute to smooth and reliable operation.
With a speed range of 300 to 2300 revolutions per minute, distributed over 12 steps, the machine can be adapted to different materials and drilling types. It is powered by a 0.55 kW motor at 230 V, making it suitable for standard workshop installations.
- Precision spindle: Guaranteed runout accuracy below 0.03 mm.
- Flexible drill table: Can be tilted by ±45° and rotated 360° for versatile use.
- Solid construction: Die-cast aluminium lever arm and stable base plate with T-slots.
- Variable speed: 12-speed gearbox with a speed range of 300 to 2300 min⁻¹.
- Safe operation: Separate emergency stop switch and 24 V DC safety low voltage.
Pros and cons
- High precision and stability when drilling
- Adjustable drill table with large range of movement
- Robust construction made of aluminium and steel
- Wide speed range with 12 steps
- Suitable for precision work in metal
- Relatively high weight of approx. 42 kg can make transport difficult
- Requires a fixed workstation and correct setup for optimal stability
Pros and cons
Pros
- High precision and stability when drilling
- Adjustable drill table with large range of movement
- Robust construction made of aluminium and steel
- Wide speed range with 12 steps
- Suitable for precision work in metal
Cons
- Relatively high weight of approx. 42 kg can make transport difficult
- Requires a fixed workstation and correct setup for optimal stability
Pros
- High precision and stability when drilling
- Adjustable drill table with large range of movement
- Robust construction made of aluminium and steel
- Wide speed range with 12 steps
- Suitable for precision work in metal
Cons
- Relatively high weight of approx. 42 kg can make transport difficult
- Requires a fixed workstation and correct setup for optimal stability
Specifications
- Model: OPTIdrill DQ 22
- Supply voltage: 230 V
- Power: 0.55 kW
- Mains frequency: 50 Hz
- Speed range: 300–2300 min⁻¹ (12 steps)
- Column diameter: 70 mm
- Drilling capacity in steel (S235JR): 20 mm
- Continuous drilling capacity in steel (S235JR): 16 mm
- Drill table: 270 × 270 mm, T-slot 14 mm, 2 slots, rotation 360°, tilt ±45°
- Max. distance spindle – drill table: 460 mm
- Max. distance spindle – machine base: 639 mm
- Spindle mount: MK 2
- Spindle stroke: 85 mm
- Throat depth: 169 mm
- Dimensions (L×W×H): approx. 700 × 351 × 1006 mm
- Weight: approx. 41.7 kg
- Drill table load capacity: 15 kg
The Proxxon TBM 220 is a small but powerful bench drill designed for precision work. It can drill holes as small as 0.5 mm, making it ideal for tasks where accuracy and control are more important than raw power.
The machine is equipped with a plan-milled die-cast aluminium worktable measuring 220 x 120 mm, providing a stable and level surface. The table features a parallel stop and a scale, making precise work easier for repeated drilling.
The hard-chromed steel column measuring 20 x 280 mm ensures stability, while the die-cast aluminium arm with precise guides contributes to the machine’s rigid and low-vibration construction.
The TBM 220 is powered by a quiet and durable, VDE-tested motor with a three-step belt drive offering three different speeds: 1,800, 4,700, and 8,500 revolutions per minute. By changing the belt, the user can choose between high speed for small drills and lower speed with higher torque for larger drills.
The machine has a quill stroke of 30 mm and a throat depth of 140 mm (distance from the centre of the column to the centre of the drill). It comes with six MICROMOT collets in sizes 1.0 – 3.2 mm, as well as a thread for mounting a keyed drill chuck.
- Precision drilling: Can drill holes up to 0.5 mm in diameter.
- Three-step belt drive: Offers three speeds – 1,800, 4,700, and 8,500 rpm.
- Stable construction: Plan-milled worktable and hard-chromed steel column ensure precision.
- Quality motor: VDE-tested motor with low noise level and long service life.
- Included collets: Six MICROMOT collets from 1.0 to 3.2 mm.
Pros and cons
- High precision and stability for small drilling tasks
- Three speed levels for different materials and drill sizes
- Compact and robust die-cast aluminium construction
- Quiet and reliable motor
- Suitable for model making, electronics, and fine mechanics
- Limited drilling capacity for larger workpieces
- Speed change requires manual belt adjustment
Pros and cons
Pros
- High precision and stability for small drilling tasks
- Three speed levels for different materials and drill sizes
- Compact and robust die-cast aluminium construction
- Quiet and reliable motor
- Suitable for model making, electronics, and fine mechanics
Cons
- Limited drilling capacity for larger workpieces
- Speed change requires manual belt adjustment
Pros
- High precision and stability for small drilling tasks
- Three speed levels for different materials and drill sizes
- Compact and robust die-cast aluminium construction
- Quiet and reliable motor
- Suitable for model making, electronics, and fine mechanics
Cons
- Limited drilling capacity for larger workpieces
- Speed change requires manual belt adjustment
Specifications
- Model: TBM 220
- Item number (SKU): ROL-28128
- Voltage: 220–240 V
- Power: 85 W
- Frequency: 50–60 Hz
- Speed: 1,800 / 4,700 / 8,500 rpm
- Throat depth: 140 mm
- Quill stroke: 30 mm
- Worktable: 220 x 120 mm, plan-milled die-cast aluminium
- Column: 20 x 280 mm, hard-chromed steel
- Collets: 6 pcs. MICROMOT (1.0 – 3.2 mm)
- Thread for drill chuck: 3/8"
- EAN / Barcode: ROL-28128
The Axminster Professional AP20BD is a bench drill designed to deliver precise results and stable operation in workshop environments. The machine is equipped with a precision spindle running in NSK ball bearings, which reduces vibration and ensures smooth rotation during drilling.
The drive system uses multi-V belts that provide good grip and contribute to quiet and stable operation. The spindle unit is firmly integrated into the main body, increasing the overall rigidity and precision of the machine.
Safety is ensured by an electrically interlocked chuck guard that prevents accidental starting, as well as a safety switch that cuts power when the belt cover is opened. An integrated LED work light provides good illumination of the work area.
The machine features an ergonomic cast iron lever with a rubber grip for comfortable operation. The keyless chuck allows for quick bit changes, and the table can be adjusted via rack and pinion. An improved depth stop system allows for precise drilling.
With its compact size and robust construction, the AP20BD is suitable for both professional workshops and demanding hobby users who want a stable and precise drill.
- Precision spindle with NSK bearings: Ensures stable and vibration-free drilling.
- Multi-V belt drive: Ensures even power transmission and low noise levels.
- Safety switches: Prevent operation when the cover is open or without protection.
- LED work light: Improves visibility during work.
- Ergonomic design: Cast iron lever with rubber grip for comfortable operation.
- Keyless chuck: Quick and easy bit changes.
Pros and cons
- Robust construction with high precision
- Low vibration and stable operation
- Safety switches and protection against accidental start
- Easy adjustment of table and drilling depth
- Integrated LED lighting for better work illumination
- Relatively high weight of 82 kg may limit mobility
- Requires a fixed workspace with sufficient space
- Manual speed adjustment via pulleys
Pros and cons
Pros
- Robust construction with high precision
- Low vibration and stable operation
- Safety switches and protection against accidental start
- Easy adjustment of table and drilling depth
- Integrated LED lighting for better work illumination
Cons
- Relatively high weight of 82 kg may limit mobility
- Requires a fixed workspace with sufficient space
- Manual speed adjustment via pulleys
Pros
- Robust construction with high precision
- Low vibration and stable operation
- Safety switches and protection against accidental start
- Easy adjustment of table and drilling depth
- Integrated LED lighting for better work illumination
Cons
- Relatively high weight of 82 kg may limit mobility
- Requires a fixed workspace with sufficient space
- Manual speed adjustment via pulleys
Specifications
- Model: AP20BD
- Voltage: 230 V
- Power: 750 W
- Speed range: 120 – 2,580 rpm
- Chuck capacity: 1 – 16 mm (keyless)
- Spindle travel: 80 mm
- Morse taper: 2 MT
- Spindle taper: 2 MT
- Column diameter: 80 mm
- Max. drilling in mild steel: 20 mm
- Max. distance chuck to base: 500 mm
- Max. distance chuck to table: 325 mm
- Table size: 290 × 290 mm
- Table tilt: 45° – 0° – 45°
- Base size: 450 × 270 mm
- Throat depth: 178 mm
- Overall size (L × W × H): 670 × 360 × 1,020 mm
- Net weight: 82 kg
- Plug type: EU 2-pin plug
- Classification: Professional
The PROMAC Bench Drill 212 is a stationary drill designed for precision work in metal and other hard materials. It is equipped with a single-speed motor and speed control via V-belt, allowing stable operation and adjustment of the speed for various drilling tasks.
The machine comes with a 16 mm quick-release chuck, a protective screen and an emergency stop switch, which increase safety during use. The table is adjustable and features cross grooves that make it easier to securely fasten workpieces during drilling.
A built-in safety system prevents automatic restart after a power failure, contributing to a safer working process. The compact size and weight of 45 kg make it suitable for both workshops and smaller production environments where a stable and precise drill is required.
- Drilling capacity of 16 mm: Suitable for drilling in steel and other metals.
- Speed control via V-belt: Provides flexibility regarding material and drilling type.
- Quick-release chuck: Fast and secure clamping of drill bits without a key.
- Adjustable table with cross grooves: Allows precise positioning of workpieces.
- Safety system against automatic start: Increases safety during power failures.
Pros and cons
- Stable construction, suitable for workshop use
- Simple speed control via V-belt
- Safety features such as emergency stop and protective screen
- Adjustable table for flexible working position
- Only one motor speed may limit flexibility for specialised tasks
- Requires manual belt change to adjust speed
Pros and cons
Pros
- Stable construction, suitable for workshop use
- Simple speed control via V-belt
- Safety features such as emergency stop and protective screen
- Adjustable table for flexible working position
Cons
- Only one motor speed may limit flexibility for specialised tasks
- Requires manual belt change to adjust speed
Pros
- Stable construction, suitable for workshop use
- Simple speed control via V-belt
- Safety features such as emergency stop and protective screen
- Adjustable table for flexible working position
Cons
- Only one motor speed may limit flexibility for specialised tasks
- Requires manual belt change to adjust speed
Specifications
- Motor voltage: 230 V
- Motor power: 0.37 kW
- Spindle taper: MK-2
- Drilling capacity in steel: Ø16 mm
- Drilling depth: 80 mm
- Number of speeds: 5 steps
- Speed range: 490–2510 min⁻¹
- Max. table load: 30 kg
- T-slot: 12 mm
- Weight: 45 kg
- Dimensions (A–J): A: 970 mm, B: 560 mm, C: 640 mm, D: 168 mm, E: 73 mm, F: 40 mm, G: 445 mm, H: 320 mm, I: 265 mm, J: 265 mm
- Item number (SKU): 212
Product descriptions
The JET Bench Drill 210 Z is a compact and stable machine designed for precision drilling in various materials. It comes with a drill chuck (0.5–13 mm) and a 75 mm machine vice, making it ready for immediate use.
The machine is equipped with a safety device combined with the drill chuck drive and a front-mounted emergency stop switch to increase safety during operation. The speed change is made via a belt drive, allowing the drilling speed to be adjusted to the material.
The drill table has two parallel 12 mm holes, and the spindle has a stroke of 53 mm. With a spindle mount of B16 and a maximum drilling diameter of 10 mm, the machine is suitable for precision work on smaller workpieces.
The motor operates at 230V and delivers 0.19 kW. The machine has five speeds from 600 to 2600 revolutions per minute, providing flexibility for various drilling tasks. The compact size and weight of 32 kg make it easy to place on a workbench.
The JET 210 Z is designed for reliability and ease of use, making it suitable for both hobby workshops and lighter professional applications.
- Five speeds: Adjustable drilling speed from 600 to 2600 rpm via belt drive.
- Safe operation: Equipped with emergency stop switch and safety device on the drill chuck.
- Compact design: Fits well on workbenches in smaller workshops.
- Stable construction: Weight of 32 kg ensures good stability during drilling.
- Delivered ready for use: Includes drill chuck (0.5–13 mm) and 75 mm machine vice.
Pros and cons
- Stable and compact construction
- Multiple speed levels via belt drive
- Built-in emergency stop switch for increased safety
- Comes with relevant accessories
- Limited drilling capacity of max. 10 mm
- Manual speed adjustment requires belt change
Pros and cons
Pros
- Stable and compact construction
- Multiple speed levels via belt drive
- Built-in emergency stop switch for increased safety
- Comes with relevant accessories
Cons
- Limited drilling capacity of max. 10 mm
- Manual speed adjustment requires belt change
Pros
- Stable and compact construction
- Multiple speed levels via belt drive
- Built-in emergency stop switch for increased safety
- Comes with relevant accessories
Cons
- Limited drilling capacity of max. 10 mm
- Manual speed adjustment requires belt change
Specifications
- Model: 210 Z
- Manufacturer: JET
- Motor voltage: 230 V
- Motor power: 0.19 kW
- Spindle mount: B16
- Maximum drilling diameter: Ø10 mm
- Distance spindle-column: 105 mm
- Spindle stroke: 53 mm
- Speeds: 5 levels (600–2600 rpm)
- Drill table: 2 parallel holes of 12 mm
- Slots (number/size): T12
- Weight: 32 kg
- Dimensions (L×W×H): 600 × 420 × 240 mm
- Included accessories: Drill chuck 0.5–13 mm, machine vice 75 mm
The Axminster Workshop AW315PD is a bench drill made of cast iron and machined steel, offering high stability and reducing vibrations during operation. It is equipped with a quiet 550 W induction motor that drives the spindle via a belt drive with 12 different speeds ranging from 210 to 2,580 revolutions per minute.
The machine features a keyless chuck with a capacity of 1 to 16 mm, making bit changes easy without tools. The drilling depth can be precisely adjusted, and the feed lever is fitted with soft grips for better control.
The table height is adjusted via a rack and pinion system, and the entire table can be swung away so that the base of the machine can be used to support larger workpieces. An adjustable safety guard and a front-mounted NVR switch contribute to safe operation.
The AW315PD is suitable for precision drilling in wood, plastic, and metals and is a practical choice for users seeking a stable and reliable machine for workshop use.
- Cast iron construction: Provides stability and reduces vibration during drilling.
- 550 W induction motor: Ensures quiet and reliable operation.
- 12 speeds: From 210 to 2,580 rpm for various materials and drilling tasks.
- Keyless chuck: Quick and easy bit changes from 1 to 16 mm.
- Adjustable table: Height and angle can be adjusted via a rack and pinion system.
Pros and cons
- Robust and vibration-damping cast iron construction
- Quiet induction motor with 12 speeds
- Easy adjustment of table height and drilling depth
- Keyless chuck for quick bit changes
- Suitable for precision work in multiple materials
- Not compatible with Morse tapers
- Relatively heavy 37 kg construction may require fixed placement
Pros and cons
Pros
- Robust and vibration-damping cast iron construction
- Quiet induction motor with 12 speeds
- Easy adjustment of table height and drilling depth
- Keyless chuck for quick bit changes
- Suitable for precision work in multiple materials
Cons
- Not compatible with Morse tapers
- Relatively heavy 37 kg construction may require fixed placement
Pros
- Robust and vibration-damping cast iron construction
- Quiet induction motor with 12 speeds
- Easy adjustment of table height and drilling depth
- Keyless chuck for quick bit changes
- Suitable for precision work in multiple materials
Cons
- Not compatible with Morse tapers
- Relatively heavy 37 kg construction may require fixed placement
Specifications
- Model: AW315PD
- Item number (SKU): AX107691
- Voltage: 230 V
- Power: 550 W
- Speeds: 12 steps (210–2,580 rpm)
- Chuck capacity: 1–16 mm
- Chuck type: Keyless
- Drilling stroke: 60 mm
- Column diameter: 60 mm
- Max. distance chuck–spindle: 430 mm
- Max. distance chuck–table: 315 mm
- Max. drilling in mild steel: 16 mm
- Table size: 198 × 198 mm
- Table tilt: 45° – 0° – 45°
- Throat depth: 127 mm
- Dimensions (L × W × H): 520 × 260 × 840 mm
- Weight: 37 kg
- Plug type: UK 3-pin plug
- User level: Home workshop
The PROMAC Bench Drill 370ELB is a stationary drill designed for precision drilling in metal and other hard materials. The machine is powered by a 230 V motor with an output of 0.75 kW and has a single speed that is adjusted via a V-belt.
It is equipped with a 16 mm self-tightening chuck, a protective shield, and an emergency stop switch for increased safety during operation. The worktable has adjustable cross grooves that provide flexibility when securing workpieces, and a safety system prevents automatic restart after a power failure.
An integrated LED work light provides targeted illumination of the drilling area, improving precision when working on detailed pieces. The machine’s construction and its weight of 74 kg contribute to stable operation with minimal vibration.
With a speed range of 290 to 2300 revolutions per minute and a drilling depth of up to 80 mm, the 370ELB is suitable for a wide range of drilling tasks in the workshop.
- Single-speed motor: Simple and reliable design with V-belt adjustment.
- Self-tightening chuck: Allows quick drill bit changes without a key.
- Safety features: Protective shield, emergency stop, and system against automatic restart.
- LED work light: Provides precise illumination of the drilling area.
- Stable construction: 74 kg machine weight reduces vibrations during operation.
Pros and cons
- Robust and stable construction
- Easy operation with V-belt adjustment
- Integrated LED lighting for better work illumination
- Safety system against automatic start
- Suitable for precision drilling in metal
- Only a single-speed motor may limit flexibility with certain materials
- Relatively heavy machine, requires a fixed place on the workbench
Pros and cons
Pros
- Robust and stable construction
- Easy operation with V-belt adjustment
- Integrated LED lighting for better work illumination
- Safety system against automatic start
- Suitable for precision drilling in metal
Cons
- Only a single-speed motor may limit flexibility with certain materials
- Relatively heavy machine, requires a fixed place on the workbench
Pros
- Robust and stable construction
- Easy operation with V-belt adjustment
- Integrated LED lighting for better work illumination
- Safety system against automatic start
- Suitable for precision drilling in metal
Cons
- Only a single-speed motor may limit flexibility with certain materials
- Relatively heavy machine, requires a fixed place on the workbench
Specifications
- Motor voltage: 230 V
- Motor power: 0.75 kW
- Spindle taper: MK-2
- Drilling capacity in steel: Ø16 mm
- Drilling depth: 80 mm
- Number of speeds: 12 steps
- Speed range: 290–2300 min⁻¹
- Table load: 40 kg
- T-slot: 12 mm
- Weight: 74 kg
- Model number / SKU: 370ELB
The Holzmann ZS40HS 400V is a stationary bench drill designed for precision work in metal and wood. It is equipped with an extra-large cast iron work table that is height adjustable and can rotate 360 degrees around the central axis. The table features 14 mm T-slots that allow secure fastening of workpieces and accessories during operation.
The machine's gear head can be adjusted in height and tilted, providing flexibility when drilling at various angles. The gears are oil-bath lubricated to ensure smooth and quiet operation as well as long service life. The powerful motor delivers continuous drilling power, making the machine suitable for demanding tasks.
For increased safety, the spindle guard is height adjustable and equipped with a microswitch. The machine comes with a drill chuck (16 mm), reducers (MT4/3 and MT3/2), wedge and drawbar, making it ready for immediate use.
With a maximum height of over two metres and a weight of 320 kg, the ZS40HS 400V is a stable and solid machine built for precision and durability in workshop environments.
- XL work table: Large cast iron table (550 × 480 mm) with 360° rotation and T-slots.
- Adjustable gear head: Can be tilted and height adjusted for flexible drilling.
- Oil-bath gearbox: Ensures smooth operation and reduced wear.
- Powerful motor: Delivers continuous drilling power for demanding tasks.
- Safety feature: Spindle guard with microswitch for increased safety.
Pros and cons
- Solid cast iron construction
- Large work surface with flexible adjustment
- Oil-bath gearbox for smooth operation
- Comes with necessary accessories
- Suitable for large and heavy workpieces
- High weight of 320 kg requires a fixed location
- Requires 400V power supply
- Not suitable for small hobby workshops with limited space
Pros and cons
Pros
- Solid cast iron construction
- Large work surface with flexible adjustment
- Oil-bath gearbox for smooth operation
- Comes with necessary accessories
- Suitable for large and heavy workpieces
Cons
- High weight of 320 kg requires a fixed location
- Requires 400V power supply
- Not suitable for small hobby workshops with limited space
Pros
- Solid cast iron construction
- Large work surface with flexible adjustment
- Oil-bath gearbox for smooth operation
- Comes with necessary accessories
- Suitable for large and heavy workpieces
Cons
- High weight of 320 kg requires a fixed location
- Requires 400V power supply
- Not suitable for small hobby workshops with limited space
Specifications
- Model: ZS40HS 400V
- Manufacturer: Holzmann
- Motor power (S6/S1): 1500/1100 W
- Voltage: 400 V
- Cable length: 2.5 m
- Table size: 550 × 480 mm
- Maximum height: 2120 mm
- Spindle travel: 120 mm
- Distance spindle–base: 1250 mm
- Maximum distance spindle–table: 790 mm
- Weight: 320 kg
- Included accessories: Drill chuck 16 mm, reducer MT4/3 and MT3/2, wedge, drawbar
The Scheppach DP16VLS is a stationary bench drill designed for precision drilling in various materials such as metal and wood. The integrated positioning laser helps to mark the drilling point accurately, making work more efficient and precise.
The machine is powered by a 500 W motor running on 230 volts and offers five different speeds from 600 to 2600 revolutions per minute. This allows the user to adjust the speed to the material and drilling task.
The chuck ranges from 3 to 16 mm, and the maximum drilling size is 16 mm. The worktable measures 160 x 168 mm, and the column diameter is 46 mm, providing stability during drilling. The spindle travel is 46 mm, and the machine has overall dimensions of 460 x 255 x 630 mm.
Weighing 17 kg, the DP16VLS is light enough to be moved when needed but still robust enough to remain stable during use. A vice is included as standard, increasing flexibility when clamping workpieces.
- Positioning laser: Ensures precise marking of the drilling point.
- Flexible speed control: Five speeds from 600 to 2600 rpm.
- Powerful motor: 500 W motor for versatile drilling tasks.
- Stable construction: 46 mm column diameter and solid base for safe operation.
- Included vice: Makes it easier to clamp workpieces during drilling.
Pros and cons
- Integrated laser for precise drilling
- Multiple speed levels for different materials
- Compact and stable construction
- Included vice increases user-friendliness
- Limited spindle travel of 46 mm can be a challenge for deeper drilling
- Not intended for heavy industrial use
Pros and cons
Pros
- Integrated laser for precise drilling
- Multiple speed levels for different materials
- Compact and stable construction
- Included vice increases user-friendliness
Cons
- Limited spindle travel of 46 mm can be a challenge for deeper drilling
- Not intended for heavy industrial use
Pros
- Integrated laser for precise drilling
- Multiple speed levels for different materials
- Compact and stable construction
- Included vice increases user-friendliness
Cons
- Limited spindle travel of 46 mm can be a challenge for deeper drilling
- Not intended for heavy industrial use
Specifications
- Motor power: 500 W – 230 V
- Revolutions/min: 1450
- Speeds: 600 / 900 / 1300 / 1800 / 2600 rpm
- Chuck: 3–16 mm
- Max. drilling size: 16 mm
- Worktable: 160 × 168 mm
- Column diameter: 46 mm
- Spindle travel: 46 mm
- Dimensions (L × W × H): 460 × 255 × 630 mm
- Weight: 17 kg
- Included accessories: Vice
- Item number (SKU): 5906810901
The Optimum OPTIdrill DQ 14 is a bench drill designed for precision drilling in metal and other materials. The machine is made of die-cast aluminium and equipped with a soft-grip handle, allowing for stable and comfortable operation.
The drill table can be tilted ±45° and rotated 360°, providing flexibility for various drilling tasks. A clearly readable depth scale and a separate emergency stop switch contribute to safe and controlled operation.
The spindle is equipped with precision ball bearings and offers a runout accuracy of less than 0.03 mm, making the machine suitable for tasks where precision is crucial. The quick-release chuck and GATES quality belt ensure efficient power transmission.
With a motor power of 0.35 kW and a speed range of 700 to 2500 revolutions per minute, distributed over five stages, the machine can be adapted to different materials and drilling types. The large base plate with T-slots ensures stability during operation.
- Precision drilling: Runout accuracy below 0.03 mm for high precision.
- Flexible drill table: Can be tilted ±45° and rotated 360° for versatile use.
- Solid construction: Die-cast aluminium with soft-grip handle for stability and comfort.
- Efficient power transmission: Equipped with GATES quality belt and precision ball bearings.
- Safe operation: Separate emergency stop switch and 24 V DC safety low voltage.
Pros and cons
- High precision and stable operation
- Adjustable and rotatable drill table
- Robust aluminium construction
- Compact size, suitable for workbenches
- Safety features such as emergency stop and low voltage
- Limited drilling capacity compared to larger pillar drills
- Requires manual speed adjustment via pulleys
Pros and cons
Pros
- High precision and stable operation
- Adjustable and rotatable drill table
- Robust aluminium construction
- Compact size, suitable for workbenches
- Safety features such as emergency stop and low voltage
Cons
- Limited drilling capacity compared to larger pillar drills
- Requires manual speed adjustment via pulleys
Pros
- High precision and stable operation
- Adjustable and rotatable drill table
- Robust aluminium construction
- Compact size, suitable for workbenches
- Safety features such as emergency stop and low voltage
Cons
- Limited drilling capacity compared to larger pillar drills
- Requires manual speed adjustment via pulleys
Specifications
- Manufacturer: Optimum
- Model: OPTIdrill DQ 14
- SKU: SM-3191040
- Column diameter: 46 mm
- Length: approx. 472 mm
- Width/Depth: approx. 283 mm
- Height: approx. 634 mm
- Weight: approx. 18.5 kg
- Drilling capacity in steel (S235JR): 13 mm
- Continuous drilling capacity in steel (S235JR): 12 mm
- Drill table size: 170 × 170 mm
- T-slot size: 14 mm (2 pieces, diagonal type)
- Drill table rotation: 360°
- Drill table angle: ±45°
- Max. distance spindle – drill table: 250 mm
- Max. distance spindle – machine base: 340 mm
- Drive power: 0.35 kW
- Supply voltage: 230 V
- Mains frequency: 50 Hz
- Speed range: 700–2500 min⁻¹ (5 stages)
- Spindle stroke: 52 mm
- Spindle mount: B16
- Throat depth: 104 mm
The Proxxon TBH is a bench drill designed for precision work where stability and accuracy are crucial. The machine is powered by a high-performance DC motor with a long service life, ensuring smooth operation and constant torque under load.
The height can be easily adjusted via a rack-and-pinion mechanism with a hand crank, allowing precise control of the drilling position. The spindle drive is equipped with triple pulleys offering three speed levels – 1080, 2400, and 4500 revolutions per minute – allowing the user to adjust the speed to the material.
The machine features a drilling depth scale with an adjustable stop, and the drill spindle is mounted in precision ball bearings to ensure stable operation. The spindle head has a 1/2" thread and fits an industrial-quality RÖHM geared chuck. In addition, the spindle can be equipped with collets (No. 28200) for additional precision work.
With a column of 45 x 500 mm, a worktable of 200 x 200 mm, and a weight of about 10 kg, the TBH is both stable and compact, making it ideal for smaller workshops and precision work in metal and plastic.
- DC motor: Durable motor with stable operation and low vibration.
- Stepwise speed control: Three speed levels (1080, 2400, and 4500 rpm) for different materials.
- Precise height adjustment: Rack and pinion with hand crank for easy and accurate adjustment.
- Stable construction: Column and table in robust design for precision drilling.
- Compatibility: Suitable for RÖHM geared chuck and collets No. 28200.
Pros and cons
- Precise and stable operation with ball bearings in the spindle
- Long service life thanks to DC motor
- Easy height adjustment with hand crank
- Option to use collets for precision drilling
- Compact and solid construction
- Limited drilling capacity compared to larger pillar drills
- Requires manual belt change to adjust speed
Pros and cons
Pros
- Precise and stable operation with ball bearings in the spindle
- Long service life thanks to DC motor
- Easy height adjustment with hand crank
- Option to use collets for precision drilling
- Compact and solid construction
Cons
- Limited drilling capacity compared to larger pillar drills
- Requires manual belt change to adjust speed
Pros
- Precise and stable operation with ball bearings in the spindle
- Long service life thanks to DC motor
- Easy height adjustment with hand crank
- Option to use collets for precision drilling
- Compact and solid construction
Cons
- Limited drilling capacity compared to larger pillar drills
- Requires manual belt change to adjust speed
Specifications
- Voltage: 220–240 V
- Speeds: 1080 / 2400 / 4500 rpm
- Spindle travel: 63 mm
- Height adjustment: 70 mm via hand crank
- Throat depth: 120 mm
- Worktable surface: 200 × 200 mm
- Column: 45 × 500 mm
- Max. drilling capacity in steel: 10 mm
- Clamping range: up to 10 mm
- Weight: approx. 10 kg
- Compatible chuck: RÖHM geared chuck (1/2" thread)
- Option for collets: No. 28200
- SKU: ROL-28124
The Record DP58B Heavy Duty is a stationary bench drill made of steel and cast iron, ensuring stability and durability. It is equipped with a powerful induction motor that provides smooth operation and can handle both hardwood and metal parts.
The machine features a cast iron table with grooves that allow secure attachment of a vice. The table can be tilted up to 45 degrees, providing flexibility when drilling at angles. A rack and pinion system makes height adjustment of the table easy.
With 12 different speeds, the user can adjust the rotation speed to the material, making the machine suitable for many types of drilling work. The spindle sleeve is designed to minimise vibrations and ensure precision during operation.
The machine has a maximum chuck capacity of 16 mm, a weight of 55 kg and an overall height of 1050 mm, making it suitable for both professional users and hobbyists who want a stable and precise drill.
- 12 speeds: Allows precise adjustment for different materials.
- Cast iron table: Can be tilted up to 45° and has grooves for attaching a vice.
- Induction motor: Provides stable performance for drilling in wood and metal.
- Solid construction: Steel and cast iron reduce vibrations and increase precision.
- Ergonomic design: Handles and height adjustment are designed for easy operation.
Pros and cons
- Robust and vibration-damping construction
- Flexible speed control with 12 levels
- Suitable for metal and woodwork
- Cast iron table with angle adjustment
- Long service life thanks to induction motor
- Relatively heavy machine, requires a fixed location
- Requires manual belt change to adjust speed
Pros and cons
Pros
- Robust and vibration-damping construction
- Flexible speed control with 12 levels
- Suitable for metal and woodwork
- Cast iron table with angle adjustment
- Long service life thanks to induction motor
Cons
- Relatively heavy machine, requires a fixed location
- Requires manual belt change to adjust speed
Pros
- Robust and vibration-damping construction
- Flexible speed control with 12 levels
- Suitable for metal and woodwork
- Cast iron table with angle adjustment
- Long service life thanks to induction motor
Cons
- Relatively heavy machine, requires a fixed location
- Requires manual belt change to adjust speed
Specifications
- Model: DP58B Heavy Duty
- Manufacturer: Record
- Item number (SKU): RECDP58B-EP
- Voltage: 230V
- Motor power P1/P2: 0.6 kW / 0.37 kW
- Throat depth: 165 mm
- Drilling depth: 80 mm
- Chuck to table: 371 mm
- Chuck to base: 548 mm
- Chuck: 16 mm
- Speeds: 180, 250, 300, 400, 480, 580, 970, 1280, 1410, 1540, 2270, 2740 rpm
- Weight: 55 kg
- Dimensions: H1050 × W270 × D563 mm
The Rotwerk RB18 Vario is a bench drill designed for precision drilling in metal and other materials. It is equipped with a variable drive that allows the spindle speed to be adjusted steplessly without having to open or disassemble the machine.
The machine is powered by a 600 W motor and is designed to maintain torque across the entire speed range. This ensures a stable and consistent drilling process regardless of speed. The drive and construction are made in Germany, supporting the machine’s quality and durability.
The RB18 Vario has a drilling capacity of up to 18 mm in steel and a spindle mount of type MK2. It is equipped with a drill chuck that clamps from 1 to 16 mm and offers two speed ranges: 290–880 min⁻¹ and 880–2400 min⁻¹. The machine has a drilling depth of 50 mm and a throat depth of 115 mm.
With a column diameter of 60 mm, a column height of 600 mm, and an overall height of 765 mm, the RB18 Vario is a stable and compact machine weighing around 31 kg. It is suitable for both workshops and hobby spaces where precision and flexibility are important.
- Variable drive: Stepless adjustment of spindle speed without disassembling the machine.
- Stable torque: Maintains performance across the entire speed range.
- German manufacturing: Drive and construction produced in Germany.
- Powerful motor: 600 W motor for demanding drilling tasks.
- Precision drilling: Drilling capacity up to 18 mm in steel.
Pros and cons
- Stepless speed control via variable drive
- Stable and robust construction
- Maintains torque at low speed
- Suitable for both professional and hobby applications
- German drive for high quality
- Relatively high weight of approx. 31 kg can make it less mobile
- Limited drilling depth of 50 mm compared to larger pillar drills
Pros and cons
Pros
- Stepless speed control via variable drive
- Stable and robust construction
- Maintains torque at low speed
- Suitable for both professional and hobby applications
- German drive for high quality
Cons
- Relatively high weight of approx. 31 kg can make it less mobile
- Limited drilling depth of 50 mm compared to larger pillar drills
Pros
- Stepless speed control via variable drive
- Stable and robust construction
- Maintains torque at low speed
- Suitable for both professional and hobby applications
- German drive for high quality
Cons
- Relatively high weight of approx. 31 kg can make it less mobile
- Limited drilling depth of 50 mm compared to larger pillar drills
Specifications
- Model: RB18 Vario
- Manufacturer: Rotwerk
- Mains voltage: 230 V / 50 Hz
- Power: 600 W
- Drill chuck: 1–16 mm
- Spindle mount: MK2
- Drilling capacity in steel: 18 mm
- Speed range I: 290–880 min⁻¹
- Speed range II: 880–2400 min⁻¹
- Torque range I: 5.3–4.0 Nm
- Torque range II: 1.8–1.3 Nm
- Throat depth: 115 mm
- Drilling depth: 50 mm
- Column diameter: 60 mm
- Column height: 600 mm
- Overall height: 765 mm
- Weight: approx. 31 kg
- SKU: RB18VARIO
The Axminster Workshop AW285PD is a bench drill designed for smaller workshops and hobby applications where precision and stability are important. The machine is made of cast iron and machined steel, providing a solid base and reducing vibrations during operation.
It is powered by a 350 W induction motor that ensures smooth and quiet operation. The user can choose between five belt speeds from 600 to 2,500 revolutions per minute, allowing the speed to be adjusted for different materials and drilling tasks.
The machine is equipped with a keyless chuck that can hold drill bits from 1 to 13 mm, as well as a depth control that ensures consistent drilling holes. The table can be adjusted in height and tilted from 45° to 0° to 45°, providing flexibility for various work tasks.
A front-mounted NVR switch and an adjustable safety guard contribute to safe operation. The belt cover also has a safety switch that prevents accidental starting during speed changes. The combination of compact size and robust construction makes the AW285PD suitable for both beginners and experienced users who need a reliable drill for precision work.
- Solid construction: Cast iron and machined steel provide stability and reduce vibrations.
- Efficient motor: 350 W induction motor with smooth and quiet operation.
- Flexible speed control: Five belt speeds from 600 to 2,500 rpm.
- Keyless chuck: Allows quick change of drill bits between 1 and 13 mm.
- Adjustable table: The table can be raised, lowered and tilted to allow precise positioning.
- Safe operation: NVR switch and safety guard increase safety during use.
Pros and cons
- Robust and vibration-damping construction
- Smooth operation with induction motor
- Multiple speed levels for different materials
- Easy operation with keyless chuck
- Compact size, suitable for smaller workshops
- Not suitable for chiselling or very heavy drilling work
- UK 3-pin plug may require an adapter when used in Denmark
Pros and cons
Pros
- Robust and vibration-damping construction
- Smooth operation with induction motor
- Multiple speed levels for different materials
- Easy operation with keyless chuck
- Compact size, suitable for smaller workshops
Cons
- Not suitable for chiselling or very heavy drilling work
- UK 3-pin plug may require an adapter when used in Denmark
Pros
- Robust and vibration-damping construction
- Smooth operation with induction motor
- Multiple speed levels for different materials
- Easy operation with keyless chuck
- Compact size, suitable for smaller workshops
Cons
- Not suitable for chiselling or very heavy drilling work
- UK 3-pin plug may require an adapter when used in Denmark
Specifications
- Model: AW285PD
- Item number (SKU): AX107690
- Voltage: 230 V
- Power: 350 W
- Speeds: 5 levels (600–2,500 rpm)
- Chuck capacity: 1–13 mm
- Chuck type: Keyless
- Drilling stroke: 50 mm
- Column diameter: 46 mm
- Max. distance chuck–spindle: 380 mm
- Max. distance chuck–table: 285 mm
- Max. drilling in mild steel: 13 mm
- Table size: 165 × 165 mm
- Table tilt: 45° – 0° – 45°
- Throat depth: 105 mm
- Dimensions (L × W × H): 500 × 280 × 735 mm
- Weight: 26 kg
- Plug type: UK 3-pin
The PROMAC Bench Drill 371ELB is a stationary drill designed for precision work in metal and other hard materials. It is powered by a 400-volt motor with an output of 0.75 kW, ensuring stable operation and sufficient power for most drilling tasks in the workshop.
The machine features speed control via a V-belt and offers 12 different speed levels ranging from 290–2300 revolutions per minute. This allows the speed to be adjusted to different materials and drill diameters.
The drill chuck is self-tightening and can accommodate drill bits up to 16 mm in diameter. The worktable is equipped with adjustable cross grooves and can support up to 40 kg, providing flexibility when securing workpieces.
For increased safety, the machine is equipped with an emergency stop, a protective screen, and a system that prevents automatic restart after a power failure. An integrated LED lamp provides targeted illumination of the drilling area, allowing work to be carried out with high precision.
- Motor: 400 V, 0.75 kW with 12 speed levels via V-belt.
- Drilling capacity: Up to 16 mm in steel.
- Safety: Emergency stop, protective screen, and anti-restart system.
- Worktable: Adjustable cross grooves and load capacity up to 40 kg.
- Lighting: Built-in LED lamp for better visibility during work.
Pros and cons
- Stable and powerful motor for precision drilling
- Ability to control speed via V-belt
- Safety features such as emergency stop and protective screen
- LED work lamp for better visibility
- Solid construction with high weight for stability
- Requires a 400 V power supply, which may limit use in private workshops
- Manual speed adjustment via V-belt can take some time
Pros and cons
Pros
- Stable and powerful motor for precision drilling
- Ability to control speed via V-belt
- Safety features such as emergency stop and protective screen
- LED work lamp for better visibility
- Solid construction with high weight for stability
Cons
- Requires a 400 V power supply, which may limit use in private workshops
- Manual speed adjustment via V-belt can take some time
Pros
- Stable and powerful motor for precision drilling
- Ability to control speed via V-belt
- Safety features such as emergency stop and protective screen
- LED work lamp for better visibility
- Solid construction with high weight for stability
Cons
- Requires a 400 V power supply, which may limit use in private workshops
- Manual speed adjustment via V-belt can take some time
Specifications
- Motor voltage: 400 V
- Motor power: 0.75 kW
- Spindle taper: MK-2
- Drilling capacity in steel: Ø16 mm
- Drilling depth: 80 mm
- Number of speeds: 12
- Speed range: 290–2300 min⁻¹
- Table load: 40 kg
- T-slot: 12 mm
- Weight: 74 kg
- Model number: 371ELB
The Holzmann SB4116HM 230V is a bench drill designed with a focus on stability and accuracy. The machine features a solid, polished base with T-slots, providing a secure foundation during operation. The stainless steel column contributes to the rigidity and precision of the machine when drilling.
The motor is an aluminium motor with IP54 protection, offering a good balance between performance and durability. The worktable can be tilted from -45° to +45° and rotated 360° around its axis, allowing drilling at various angles and positions.
The machine comes with a self-tightening drill chuck (3–16 mm, B16), and the spindle is equipped with a protective cover for increased safety. The combination of adjustability, power, and precision makes it suitable for both metal and woodwork in smaller workshops.
With a maximum drilling capacity of 16 mm, 12 speed levels from 180 to 2740 revolutions per minute, and a maximum height of 1060 mm, the SB4116HM offers a flexible working platform for many types of drilling tasks.
- Powerful motor: 600 W (S1) / 900 W (S6) with IP54 protection.
- Adjustable worktable: Can be tilted from -45° to +45° and rotated 360°.
- Solid construction: Stainless steel column and polished base with T-slots.
- Flexible drilling capacity: Up to 16 mm drilling diameter and 12 speed levels.
- Safety: Spindle guard and stable base for precise work.
Pros and cons
- Stable and robust stainless steel construction
- Adjustable and rotatable worktable
- Powerful motor with IP54 protection
- Suitable for metal and woodwork
- Comes with self-tightening drill chuck
- Relatively high weight of 50 kg can make it less mobile
- Requires a fixed workspace and proper setup for optimal precision
Pros and cons
Pros
- Stable and robust stainless steel construction
- Adjustable and rotatable worktable
- Powerful motor with IP54 protection
- Suitable for metal and woodwork
- Comes with self-tightening drill chuck
Cons
- Relatively high weight of 50 kg can make it less mobile
- Requires a fixed workspace and proper setup for optimal precision
Pros
- Stable and robust stainless steel construction
- Adjustable and rotatable worktable
- Powerful motor with IP54 protection
- Suitable for metal and woodwork
- Comes with self-tightening drill chuck
Cons
- Relatively high weight of 50 kg can make it less mobile
- Requires a fixed workspace and proper setup for optimal precision
Specifications
- Model: SB4116HM 230V
- Motor power (S1/S6): 600 W / 900 W
- Voltage: 230 V
- Table size: 250 × 250 mm
- Maximum height: 1060 mm
- Distance from chuck to column: 170 mm
- Maximum drilling stroke: 80 mm
- Base plate: 270 × 450 mm
- Maximum drilling capacity: 16 mm
- Spindle speed: 12 levels, 180–2740 min⁻¹
- Distance from spindle to base plate: 695 mm
- Distance between spindle and table: 495 mm
- Net weight: 50 kg
- Package dimensions (L×W×H): 895 × 490 × 290 mm
- Scope of delivery: Self-tightening drill chuck 3–16 mm, B16
The Optimum OPTIdrill DQ 22 is a bench drill designed for precision work and stable operation. The machine is equipped with a separate emergency stop switch and a drilling depth limiter, which increases safety and allows repeated drilling operations with high accuracy.
The drill table is precisely machined and can be tilted by ±45° and rotated 360°, providing flexibility for various drilling tasks. The table has diagonally arranged T-slots and a surrounding coolant groove, making it suitable for metalworking.
The machine features a die-cast aluminium lever arm with a soft-grip handle, and the spindle is mounted with precision ball bearings to ensure a runout accuracy of less than 0.03 mm. The quick-release chuck and GATES quality belt contribute to smooth and reliable operation.
With a speed range of 300 to 2300 revolutions per minute, distributed over 12 steps, the machine can be adapted to different materials and drilling types. It is powered by a 0.55 kW motor at 230 V, making it suitable for standard workshop installations.
- Precision spindle: Guaranteed runout accuracy below 0.03 mm.
- Flexible drill table: Can be tilted by ±45° and rotated 360° for versatile use.
- Solid construction: Die-cast aluminium lever arm and stable base plate with T-slots.
- Variable speed: 12-speed gearbox with a speed range of 300 to 2300 min⁻¹.
- Safe operation: Separate emergency stop switch and 24 V DC safety low voltage.
Pros and cons
- High precision and stability when drilling
- Adjustable drill table with large range of movement
- Robust construction made of aluminium and steel
- Wide speed range with 12 steps
- Suitable for precision work in metal
- Relatively high weight of approx. 42 kg can make transport difficult
- Requires a fixed workstation and correct setup for optimal stability
Pros and cons
Pros
- High precision and stability when drilling
- Adjustable drill table with large range of movement
- Robust construction made of aluminium and steel
- Wide speed range with 12 steps
- Suitable for precision work in metal
Cons
- Relatively high weight of approx. 42 kg can make transport difficult
- Requires a fixed workstation and correct setup for optimal stability
Pros
- High precision and stability when drilling
- Adjustable drill table with large range of movement
- Robust construction made of aluminium and steel
- Wide speed range with 12 steps
- Suitable for precision work in metal
Cons
- Relatively high weight of approx. 42 kg can make transport difficult
- Requires a fixed workstation and correct setup for optimal stability
Specifications
- Model: OPTIdrill DQ 22
- Supply voltage: 230 V
- Power: 0.55 kW
- Mains frequency: 50 Hz
- Speed range: 300–2300 min⁻¹ (12 steps)
- Column diameter: 70 mm
- Drilling capacity in steel (S235JR): 20 mm
- Continuous drilling capacity in steel (S235JR): 16 mm
- Drill table: 270 × 270 mm, T-slot 14 mm, 2 slots, rotation 360°, tilt ±45°
- Max. distance spindle – drill table: 460 mm
- Max. distance spindle – machine base: 639 mm
- Spindle mount: MK 2
- Spindle stroke: 85 mm
- Throat depth: 169 mm
- Dimensions (L×W×H): approx. 700 × 351 × 1006 mm
- Weight: approx. 41.7 kg
- Drill table load capacity: 15 kg
The Proxxon TBM 220 is a small but powerful bench drill designed for precision work. It can drill holes as small as 0.5 mm, making it ideal for tasks where accuracy and control are more important than raw power.
The machine is equipped with a plan-milled die-cast aluminium worktable measuring 220 x 120 mm, providing a stable and level surface. The table features a parallel stop and a scale, making precise work easier for repeated drilling.
The hard-chromed steel column measuring 20 x 280 mm ensures stability, while the die-cast aluminium arm with precise guides contributes to the machine’s rigid and low-vibration construction.
The TBM 220 is powered by a quiet and durable, VDE-tested motor with a three-step belt drive offering three different speeds: 1,800, 4,700, and 8,500 revolutions per minute. By changing the belt, the user can choose between high speed for small drills and lower speed with higher torque for larger drills.
The machine has a quill stroke of 30 mm and a throat depth of 140 mm (distance from the centre of the column to the centre of the drill). It comes with six MICROMOT collets in sizes 1.0 – 3.2 mm, as well as a thread for mounting a keyed drill chuck.
- Precision drilling: Can drill holes up to 0.5 mm in diameter.
- Three-step belt drive: Offers three speeds – 1,800, 4,700, and 8,500 rpm.
- Stable construction: Plan-milled worktable and hard-chromed steel column ensure precision.
- Quality motor: VDE-tested motor with low noise level and long service life.
- Included collets: Six MICROMOT collets from 1.0 to 3.2 mm.
Pros and cons
- High precision and stability for small drilling tasks
- Three speed levels for different materials and drill sizes
- Compact and robust die-cast aluminium construction
- Quiet and reliable motor
- Suitable for model making, electronics, and fine mechanics
- Limited drilling capacity for larger workpieces
- Speed change requires manual belt adjustment
Pros and cons
Pros
- High precision and stability for small drilling tasks
- Three speed levels for different materials and drill sizes
- Compact and robust die-cast aluminium construction
- Quiet and reliable motor
- Suitable for model making, electronics, and fine mechanics
Cons
- Limited drilling capacity for larger workpieces
- Speed change requires manual belt adjustment
Pros
- High precision and stability for small drilling tasks
- Three speed levels for different materials and drill sizes
- Compact and robust die-cast aluminium construction
- Quiet and reliable motor
- Suitable for model making, electronics, and fine mechanics
Cons
- Limited drilling capacity for larger workpieces
- Speed change requires manual belt adjustment
Specifications
- Model: TBM 220
- Item number (SKU): ROL-28128
- Voltage: 220–240 V
- Power: 85 W
- Frequency: 50–60 Hz
- Speed: 1,800 / 4,700 / 8,500 rpm
- Throat depth: 140 mm
- Quill stroke: 30 mm
- Worktable: 220 x 120 mm, plan-milled die-cast aluminium
- Column: 20 x 280 mm, hard-chromed steel
- Collets: 6 pcs. MICROMOT (1.0 – 3.2 mm)
- Thread for drill chuck: 3/8"
- EAN / Barcode: ROL-28128
The Axminster Professional AP20BD is a bench drill designed to deliver precise results and stable operation in workshop environments. The machine is equipped with a precision spindle running in NSK ball bearings, which reduces vibration and ensures smooth rotation during drilling.
The drive system uses multi-V belts that provide good grip and contribute to quiet and stable operation. The spindle unit is firmly integrated into the main body, increasing the overall rigidity and precision of the machine.
Safety is ensured by an electrically interlocked chuck guard that prevents accidental starting, as well as a safety switch that cuts power when the belt cover is opened. An integrated LED work light provides good illumination of the work area.
The machine features an ergonomic cast iron lever with a rubber grip for comfortable operation. The keyless chuck allows for quick bit changes, and the table can be adjusted via rack and pinion. An improved depth stop system allows for precise drilling.
With its compact size and robust construction, the AP20BD is suitable for both professional workshops and demanding hobby users who want a stable and precise drill.
- Precision spindle with NSK bearings: Ensures stable and vibration-free drilling.
- Multi-V belt drive: Ensures even power transmission and low noise levels.
- Safety switches: Prevent operation when the cover is open or without protection.
- LED work light: Improves visibility during work.
- Ergonomic design: Cast iron lever with rubber grip for comfortable operation.
- Keyless chuck: Quick and easy bit changes.
Pros and cons
- Robust construction with high precision
- Low vibration and stable operation
- Safety switches and protection against accidental start
- Easy adjustment of table and drilling depth
- Integrated LED lighting for better work illumination
- Relatively high weight of 82 kg may limit mobility
- Requires a fixed workspace with sufficient space
- Manual speed adjustment via pulleys
Pros and cons
Pros
- Robust construction with high precision
- Low vibration and stable operation
- Safety switches and protection against accidental start
- Easy adjustment of table and drilling depth
- Integrated LED lighting for better work illumination
Cons
- Relatively high weight of 82 kg may limit mobility
- Requires a fixed workspace with sufficient space
- Manual speed adjustment via pulleys
Pros
- Robust construction with high precision
- Low vibration and stable operation
- Safety switches and protection against accidental start
- Easy adjustment of table and drilling depth
- Integrated LED lighting for better work illumination
Cons
- Relatively high weight of 82 kg may limit mobility
- Requires a fixed workspace with sufficient space
- Manual speed adjustment via pulleys
Specifications
- Model: AP20BD
- Voltage: 230 V
- Power: 750 W
- Speed range: 120 – 2,580 rpm
- Chuck capacity: 1 – 16 mm (keyless)
- Spindle travel: 80 mm
- Morse taper: 2 MT
- Spindle taper: 2 MT
- Column diameter: 80 mm
- Max. drilling in mild steel: 20 mm
- Max. distance chuck to base: 500 mm
- Max. distance chuck to table: 325 mm
- Table size: 290 × 290 mm
- Table tilt: 45° – 0° – 45°
- Base size: 450 × 270 mm
- Throat depth: 178 mm
- Overall size (L × W × H): 670 × 360 × 1,020 mm
- Net weight: 82 kg
- Plug type: EU 2-pin plug
- Classification: Professional
The PROMAC Bench Drill 212 is a stationary drill designed for precision work in metal and other hard materials. It is equipped with a single-speed motor and speed control via V-belt, allowing stable operation and adjustment of the speed for various drilling tasks.
The machine comes with a 16 mm quick-release chuck, a protective screen and an emergency stop switch, which increase safety during use. The table is adjustable and features cross grooves that make it easier to securely fasten workpieces during drilling.
A built-in safety system prevents automatic restart after a power failure, contributing to a safer working process. The compact size and weight of 45 kg make it suitable for both workshops and smaller production environments where a stable and precise drill is required.
- Drilling capacity of 16 mm: Suitable for drilling in steel and other metals.
- Speed control via V-belt: Provides flexibility regarding material and drilling type.
- Quick-release chuck: Fast and secure clamping of drill bits without a key.
- Adjustable table with cross grooves: Allows precise positioning of workpieces.
- Safety system against automatic start: Increases safety during power failures.
Pros and cons
- Stable construction, suitable for workshop use
- Simple speed control via V-belt
- Safety features such as emergency stop and protective screen
- Adjustable table for flexible working position
- Only one motor speed may limit flexibility for specialised tasks
- Requires manual belt change to adjust speed
Pros and cons
Pros
- Stable construction, suitable for workshop use
- Simple speed control via V-belt
- Safety features such as emergency stop and protective screen
- Adjustable table for flexible working position
Cons
- Only one motor speed may limit flexibility for specialised tasks
- Requires manual belt change to adjust speed
Pros
- Stable construction, suitable for workshop use
- Simple speed control via V-belt
- Safety features such as emergency stop and protective screen
- Adjustable table for flexible working position
Cons
- Only one motor speed may limit flexibility for specialised tasks
- Requires manual belt change to adjust speed
Specifications
- Motor voltage: 230 V
- Motor power: 0.37 kW
- Spindle taper: MK-2
- Drilling capacity in steel: Ø16 mm
- Drilling depth: 80 mm
- Number of speeds: 5 steps
- Speed range: 490–2510 min⁻¹
- Max. table load: 30 kg
- T-slot: 12 mm
- Weight: 45 kg
- Dimensions (A–J): A: 970 mm, B: 560 mm, C: 640 mm, D: 168 mm, E: 73 mm, F: 40 mm, G: 445 mm, H: 320 mm, I: 265 mm, J: 265 mm
- Item number (SKU): 212
Other products
The Holzmann GBM25 400V is a stationary bench drill designed for demanding drilling tasks. The machine is equipped with a 400V motor with two stages and a total output of 650/900 W, providing sufficient power for working with metal and wood.
The drill head can be rotated 360 degrees and adjusted in height, offering great flexibility for various work tasks. The vibration-free and robust construction ensures precise results even during prolonged use.
The machine has eight different speeds, allowing the drilling speed to be adjusted to the material. The table is equipped with T-slots and a T-stop, ensuring stable fastening of the workpieces during operation.
With a maximum drilling capacity of 25 mm and thread cutting up to M10, the GBM25 400V is suitable for both professional users and advanced hobbyists who want a reliable and powerful drill for workshop use.
- Powerful motor: 650/900 W two-stage motor with 400V operating voltage.
- Flexible drilling device: The drill head can be rotated 360° and adjusted in height.
- Precision work: Vibration-free construction and solid base for stable drilling.
- Variable speed: 8 speeds, adapted to different materials.
- Large drilling capacity: Up to 25 mm drilling diameter and thread cutting up to M10.
Pros and cons
- Robust and vibration-free construction
- Two-stage motor with high power
- 360° rotatable and height-adjustable drill head
- Multiple speed levels for precise control
- Suitable for working with metal and wood
- Requires a 400V power supply, which limits use in normal households
- Relatively heavy and stationary – not suitable for mobile use
Pros and cons
Pros
- Robust and vibration-free construction
- Two-stage motor with high power
- 360° rotatable and height-adjustable drill head
- Multiple speed levels for precise control
- Suitable for working with metal and wood
Cons
- Requires a 400V power supply, which limits use in normal households
- Relatively heavy and stationary – not suitable for mobile use
Pros
- Robust and vibration-free construction
- Two-stage motor with high power
- 360° rotatable and height-adjustable drill head
- Multiple speed levels for precise control
- Suitable for working with metal and wood
Cons
- Requires a 400V power supply, which limits use in normal households
- Relatively heavy and stationary – not suitable for mobile use
Specifications
- Motor power (S1): 650/900 W
- Voltage: 400V
- Throat depth: 255 mm
- Table size: 500 × 350 mm
- Spindle taper: MK3/MT3
- Maximum drilling capacity: 25 mm
- Maximum thread size: M10
- Quill stroke: 120 mm
- Column diameter: 100 mm
- Base: 500 × 400 mm
- T-slots: 14 mm
The Optimum OPTIdrill DQ 18 is a bench drill designed for precision drilling in metal and other hard materials. The machine is equipped with a precision spindle with ball bearings and a high-quality quick-action drill chuck, ensuring stable operation and precise results.
The drill table is made of robust material and can be tilted ±45° and rotated 360°, offering flexibility for various drilling tasks. The table features diagonally arranged T-slots and a surrounding coolant groove, making it suitable for precision work and efficient cooling.
The machine is powered by a 0.45 kW motor with five speed levels ranging from 600 to 2400 revolutions per minute. It is equipped with a GATES quality belt for stable power transmission and low vibration during operation.
Safety is ensured by a separate emergency stop switch and a 24 V DC low-voltage control. The solid column and base plate with T-slots provide the machine with a stable foundation, while the die-cast aluminium feed lever with soft-grip handle allows comfortable operation.
- Precision spindle: Ball bearings and runout accuracy below 0.03 mm.
- Adjustable drill table: Can be tilted ±45° and rotated 360° for flexible machining.
- Stable construction: Robust column and ribbed base plate with T-slots.
- Safe operation: Separate emergency stop switch and 24 V DC safety low voltage.
- Variable speed: Five gears from 600 to 2400 revolutions per minute.
Pros and cons
- High precision and stable operation
- Flexible drill table with tilt and rotation
- Solid construction with quality components
- Safety features with emergency stop and low voltage
- Suitable for metal and woodwork
- Relatively heavy construction of approx. 28.5 kg may require a fixed workstation
- Manual speed adjustment via pulleys
Pros and cons
Pros
- High precision and stable operation
- Flexible drill table with tilt and rotation
- Solid construction with quality components
- Safety features with emergency stop and low voltage
- Suitable for metal and woodwork
Cons
- Relatively heavy construction of approx. 28.5 kg may require a fixed workstation
- Manual speed adjustment via pulleys
Pros
- High precision and stable operation
- Flexible drill table with tilt and rotation
- Solid construction with quality components
- Safety features with emergency stop and low voltage
- Suitable for metal and woodwork
Cons
- Relatively heavy construction of approx. 28.5 kg may require a fixed workstation
- Manual speed adjustment via pulleys
Specifications
- Manufacturer: Optimum
- Model: OPTIdrill DQ 18
- SKU: SM-3191042
- Column diameter: 60 mm
- Length: approx. 568 mm
- Width/Depth: approx. 319 mm
- Height: approx. 849 mm
- Weight: approx. 28.5 kg
- Drilling capacity steel (S235JR): 15.9 mm
- Continuous drilling capacity steel (S235JR): 14 mm
- Drill table size: 200 × 200 mm
- T-slot size: 14 mm (2 pieces, diagonal type)
- Rotation: 360°
- Angle: ±45°
- Load capacity: 12 kg
- Max. distance spindle – drill table: 319 mm
- Motor power: 0.45 kW
- Supply voltage: 230 V
- Mains frequency: 50 Hz
- Max. distance spindle – machine base: 518 mm
- Speed range: 600–2400 min⁻¹ (5 levels)
- Spindle mount: MK 2
- Drilling stroke: 65 mm
- Throat depth: 127 mm
The Axminster Professional AP340PD is a compact bench drill that combines many features of larger models in a more space-saving design. It is made of cast iron to ensure stability and vibration damping during operation.
The machine is powered by a 550 W induction motor that provides smooth operation and low noise levels. It offers 12 belt speeds from 210 to 2,580 revolutions per minute, making it suitable for various drilling tasks in wood and metal.
The chuck is keyless and clamps from 1 to 16 mm, mounted on a 2MT spindle. The table can be height-adjusted via rack and pinion and swung away so that the base of the machine can be used as a work support.
Safety is ensured by an electrically interlocked chuck guard, a safety switch on the belt cover and an emergency stop function on the on/off switch. An integrated LED work light provides better visibility during work.
The machine is suitable for professional workshops, educational institutions and users who want a precise and solid drill for stationary use.
- Cast iron construction: Provides high stability and reduces vibrations.
- 12 belt speeds: From 210 to 2,580 rpm for flexible drilling control.
- Keyless chuck: 1–16 mm capacity, mounted on 2MT spindle.
- Safety switches: Prevent operation with the belt cover open and protect the user.
- LED work light: Improves visibility during precision work.
- Adjustable table: Height adjustment via rack and pinion, can be swung away for larger workpieces.
Pros and cons
- Solid and vibration-damping cast iron construction
- Wide speed range with 12 steps
- Keyless chuck for quick tool changes
- Integrated LED light and emergency stop for increased safety
- Suitable for professional and educational environments
- Relatively heavy construction of 63 kg requires a fixed location
- Not suitable for use with mortising attachments
- Comes with a UK plug, which may require an adapter
Pros and cons
Pros
- Solid and vibration-damping cast iron construction
- Wide speed range with 12 steps
- Keyless chuck for quick tool changes
- Integrated LED light and emergency stop for increased safety
- Suitable for professional and educational environments
Cons
- Relatively heavy construction of 63 kg requires a fixed location
- Not suitable for use with mortising attachments
- Comes with a UK plug, which may require an adapter
Pros
- Solid and vibration-damping cast iron construction
- Wide speed range with 12 steps
- Keyless chuck for quick tool changes
- Integrated LED light and emergency stop for increased safety
- Suitable for professional and educational environments
Cons
- Relatively heavy construction of 63 kg requires a fixed location
- Not suitable for use with mortising attachments
- Comes with a UK plug, which may require an adapter
Specifications
- Model: AP340PD
- Item number (SKU): AX107704
- Spindle distance: 420 mm x 250 mm
- Chuck: 1–16 mm keyless
- Column diameter: 70 mm
- Max. distance from chuck to spindle: 530 mm
- Max. distance from chuck to table: 340 mm
- Max. drilling capacity in mild steel: 16 mm
- Morse taper: 2 MT
- Spindle taper: 2 MT
- Power: 550 W induction motor
- Speed: 210–2,580 rpm (12 steps)
- Table size: 260 mm x 260 mm
- Table tilt: 45° – 0° – 45°
- Throat depth: 165 mm
- Voltage: 230 V
- Weight: 63 kg
- Dimensions (L x W x H): 640 x 370 x 1,000 mm
- Plug type: UK plug with 3 pins
- User level: Retail/professional use
The PROMAC bench drill JDT-2512V is a stationary machine designed for precision drilling in metal and other hard materials. It is made of cast iron, which provides high stability and reduces vibrations during operation.
The machine has a drilling capacity of up to 23 mm in mild steel and a spindle speed that can be continuously adjusted in the range of 100–2100 revolutions per minute. This allows the speed to be adapted to different materials and drilling tasks.
The worktable can be tilted ±45° and has a load capacity of 60 kg, providing flexibility for angle drilling. The table and base are made of cast iron to ensure a solid working surface.
With a spindle travel of 100 mm, a column diameter of 70 mm, and an overall height of 1040 mm, the machine is suitable for both small and medium-sized workpieces. It is equipped with an MT-2 spindle mount and a B16 drill chuck with a capacity of 1–16 mm.
- Variable speed: Adjustable spindle speed from 100 to 2100 rpm.
- Stable construction: Cast iron in head, table, and base for maximum stability.
- Large drilling capacity: Up to 23 mm in mild steel.
- Flexible worktable: Can be tilted ±45° and supports up to 60 kg.
- Precision spindle: MT-2 mount and 100 mm spindle travel for precise drilling.
Pros and cons
- Robust and vibration-damping cast iron construction
- Variable speed for different materials
- Large drilling capacity and precise spindle guidance
- Flexible worktable with tilt function
- Relatively high weight of 91 kg may limit mobility
- Requires a fixed workspace and proper setup for optimal use
Pros and cons
Pros
- Robust and vibration-damping cast iron construction
- Variable speed for different materials
- Large drilling capacity and precise spindle guidance
- Flexible worktable with tilt function
Cons
- Relatively high weight of 91 kg may limit mobility
- Requires a fixed workspace and proper setup for optimal use
Pros
- Robust and vibration-damping cast iron construction
- Variable speed for different materials
- Large drilling capacity and precise spindle guidance
- Flexible worktable with tilt function
Cons
- Relatively high weight of 91 kg may limit mobility
- Requires a fixed workspace and proper setup for optimal use
Specifications
- Model: JDT-2512V
- Drilling capacity (mild steel): 23 mm
- Thread cutting capacity (mild steel): M14
- Drill chuck size: B16 (1–16 mm)
- Spindle travel: 100 mm
- Distance from chuck to base: 500 mm
- Distance from chuck to table (max): 255 mm
- Table size: 246 × 278 mm
- Table travel: 224 mm
- Table tilt: ±45°
- Table load capacity: 60 kg
- Head travel: 345 mm
- Spindle mount: MT-2
- Column diameter: Ø70 mm
- Spindle speed range: 100–2100 rpm
- Pulley material: Cast iron
- Base size: 340 × 520 mm
- Base working area: 258 × 275 mm
- Material (table, base, head): Cast iron
- Spindle distance to column: 203 mm
- Overall dimensions (L×W×H): 690 × 410 × 1040 mm
- Net weight: 91 kg
The Holzmann SB4115N 230V is a stable bench drill designed for precision work in wood and metal. The machine is built with a solid, brushed column that ensures stability during drilling and features a worktable that can be tilted 45 degrees to either side and rotated 360 degrees for flexible positioning.
The motor is made of aluminium and has IP54 protection, ensuring a robust and reliable construction. A transparent cover protects the drill chuck, while the handle with integrated depth scale allows for precise drilling.
The machine comes with a self-tightening drill chuck and has a maximum drilling capacity of 16 mm. The variable spindle speed ranges from 200 to 2500 revolutions per minute, making it suitable for various materials and drilling tasks.
With a net weight of 30 kg and compact dimensions, the SB4115N 230V is a practical solution for both smaller workshops and hobby users who want a stable and versatile drill.
- Solid construction: Brushed column and stable base ensure precise drilling operations.
- Tilting worktable: Can be tilted +45°/-45° and rotated 360° for flexible use.
- Aluminium motor IP54: Provides reliability and protection against dust and moisture.
- Precise depth scale: Handle with integrated measuring scale for accurate drilling.
- Variable speed: 12 levels from 200 to 2500 revolutions per minute.
Pros and cons
- Robust and stable construction
- Flexible worktable with tilt and rotation function
- Self-tightening drill chuck included
- Precise depth scale for controlled drilling
- Suitable for wood and metal
- Relatively heavy compared to smaller hobby drills
- Requires a fixed workspace due to weight and size
Pros and cons
Pros
- Robust and stable construction
- Flexible worktable with tilt and rotation function
- Self-tightening drill chuck included
- Precise depth scale for controlled drilling
- Suitable for wood and metal
Cons
- Relatively heavy compared to smaller hobby drills
- Requires a fixed workspace due to weight and size
Pros
- Robust and stable construction
- Flexible worktable with tilt and rotation function
- Self-tightening drill chuck included
- Precise depth scale for controlled drilling
- Suitable for wood and metal
Cons
- Relatively heavy compared to smaller hobby drills
- Requires a fixed workspace due to weight and size
Specifications
- Model: SB4115N-230V
- Motor power S1/S6: 400 W / 600 W
- Voltage: 230 V
- Table size: 200 × 200 mm
- Maximum height: 850 mm
- Distance from chuck to column: 127 mm
- Machine dimensions (without long table): 550 × 370 × 550 mm
- Maximum stroke: 60 mm
- Base plate: 350 × 210 mm
- Maximum drilling capacity: 16 mm
- Spindle speed: 12 levels, 200–2500 min⁻¹
- Distance from spindle to base plate: 525 mm
- Distance between spindle and table: 360 mm
- Net weight: 30 kg
- Package dimensions (L×W×H): 690 × 430 × 260 mm
The Holzmann SB4116HM 400V is a stable bench drill designed for precision work. It features a solid and polished base with T-slots, providing a secure foundation during drilling.
The machine is powered by an aluminium motor with IP54 protection, making it resistant to dust and moisture. The column is made of stainless, polished steel, contributing to both strength and durability.
The worktable can be tilted from -45° to +45° and rotated 360° around its centre, offering great flexibility for various drilling tasks. A protective cover around the spindle increases safety during use.
The delivery includes a self-tightening drill chuck (3–16 mm, B16), so the machine is ready for use upon delivery.
- Powerful motor: 600 W (S1) / 900 W (S6) with 400 V operating voltage.
- Flexible worktable: Can be tilted from -45° to +45° and rotated 360°.
- Robust construction: Stainless steel column and solid base with T-slots.
- Safety: Protective cover around the spindle.
- Precision: Maximum drilling capacity of 16 mm and 12 speed levels from 180 to 2740 revolutions per minute.
Pros and cons
- Stable and robust stainless steel construction
- Adjustable and rotatable worktable for flexible drilling
- Powerful motor with multiple speed levels
- Comes with a self-tightening drill chuck
- Requires a 400 V power supply, which is not available in all workshops
- The weight of 50 kg makes it less mobile
Pros and cons
Pros
- Stable and robust stainless steel construction
- Adjustable and rotatable worktable for flexible drilling
- Powerful motor with multiple speed levels
- Comes with a self-tightening drill chuck
Cons
- Requires a 400 V power supply, which is not available in all workshops
- The weight of 50 kg makes it less mobile
Pros
- Stable and robust stainless steel construction
- Adjustable and rotatable worktable for flexible drilling
- Powerful motor with multiple speed levels
- Comes with a self-tightening drill chuck
Cons
- Requires a 400 V power supply, which is not available in all workshops
- The weight of 50 kg makes it less mobile
Specifications
- Model: SB4116HM-400V
- Motor power (S1/S6): 600 W / 900 W
- Voltage: 400 V
- Table size: 250 × 250 mm
- Maximum height: 1060 mm
- Distance from chuck to column: 170 mm
- Maximum stroke: 80 mm
- Base plate: 270 × 450 mm
- Maximum drilling capacity: 16 mm
- Spindle speed: 12 levels, 180–2740 min⁻¹
- Distance from spindle to base plate: 695 mm
- Maximum distance between spindle and table: 495 mm
- Net weight: 50 kg
- Package dimensions (L×W×H): 895 × 490 × 290 mm
- Scope of delivery: Self-tightening drill chuck 3–16 mm, B16
The Holzmann SB4115N 400V is a stationary bench drill designed for stable and precise drilling. The machine is built with a solid, brushed column that ensures rigidity during operation, and an aluminium motor with IP54 protection, contributing to operational safety and long service life.
The worktable can be rotated 360 degrees and tilted from +45 to -45 degrees, offering flexibility when drilling at various angles. An integrated depth scale on the handle allows precise control of drilling depth.
The machine comes with a self-tightening drill chuck and has a maximum drilling capacity of 16 mm. The spindle speed can be adjusted in 12 steps from 200 to 2500 revolutions per minute, allowing it to be adapted to different materials and drilling tasks.
With a maximum height of 850 mm and a net weight of 30 kg, the SB4115N 400V is a compact yet stable machine, well suited for smaller workshops and hobby users who value precision and reliability in their drilling work.
- Solid construction: Strong column and base ensure stability during drilling.
- Adjustable worktable: Can be rotated 360° and tilted ±45° for flexible use.
- Aluminium motor IP54: Provides operational safety and protection against dust and moisture.
- Depth scale: Allows precise control of drilling depth.
- Variable speed: 12 steps from 200 to 2500 revolutions per minute.
Pros and cons
- Stable and robust construction
- Flexible worktable with tilt and rotation function
- Self-tightening drill chuck included
- Option for precise depth control
- Suitable for metal and woodwork
- Relatively heavy for transport and movement
- Requires a fixed workspace for optimal stability
Pros and cons
Pros
- Stable and robust construction
- Flexible worktable with tilt and rotation function
- Self-tightening drill chuck included
- Option for precise depth control
- Suitable for metal and woodwork
Cons
- Relatively heavy for transport and movement
- Requires a fixed workspace for optimal stability
Pros
- Stable and robust construction
- Flexible worktable with tilt and rotation function
- Self-tightening drill chuck included
- Option for precise depth control
- Suitable for metal and woodwork
Cons
- Relatively heavy for transport and movement
- Requires a fixed workspace for optimal stability
Specifications
- Model: SB4115N 400V
- Motor power S1 / S6: 400 W / 600 W
- Voltage: 230 V
- Table size: 193 × 200 mm
- Maximum height: 850 mm
- Distance from chuck to column: 127 mm
- Maximum stroke: 60 mm
- Base plate: 350 × 210 mm
- Maximum drilling capacity: 16 mm
- Spindle speed: 12 steps, 200–2500 min⁻¹
- Distance from spindle to base plate: 525 mm
- Maximum distance between spindle and table: 360 mm
- Net weight: 30 kg
- Package dimensions (L × W × H): 690 × 430 × 260 mm
- Scope of delivery: Self-tightening drill chuck
The Holzmann GBM25T 400V is a stationary bench drill designed for demanding drilling tasks. The machine is equipped with a gearbox that allows the user to control the drilling with high precision and adjust the speed to the material.
The solid and vibration-free construction ensures stable operation, while the integrated T-stop in the table provides good support during work. The drill head can be rotated 360 degrees and adjusted in height, making the machine flexible in use.
The GBM25T has eight different speeds and two powerful motor stages, making it suitable for both fine drilling and more demanding tasks. The combination of robust design and adjustable features makes it a versatile tool in professional and semi-professional workshops.
- Powerful motor: 650/900 W motor with 400V operation ensures high performance.
- Precise drilling control: Gear system and 8 speeds offer flexibility at work.
- 360° rotatable drill head: Allows drilling from multiple angles.
- Solid construction: Vibration-free and robust design for stable operation.
- Adjustable table: Table with T-stop and adjustable height for precise positioning.
Pros and cons
- Powerful and stable construction
- Ability to precisely adjust speed
- Rotatable and height-adjustable drill head
- Suitable for metal and wood processing
- Requires 400V power supply
- Relatively heavy and stationary – not suitable for mobile use
Pros and cons
Pros
- Powerful and stable construction
- Ability to precisely adjust speed
- Rotatable and height-adjustable drill head
- Suitable for metal and wood processing
Cons
- Requires 400V power supply
- Relatively heavy and stationary – not suitable for mobile use
Pros
- Powerful and stable construction
- Ability to precisely adjust speed
- Rotatable and height-adjustable drill head
- Suitable for metal and wood processing
Cons
- Requires 400V power supply
- Relatively heavy and stationary – not suitable for mobile use
Specifications
- Motor power (S1): 650/900 W
- Voltage: 400V
- Throat depth: 255 mm
- Table size: 250 × 290 mm
- Taper: MK3/MT3
- Max. drilling capacity: 25 mm
- Max. thread size: M10
- Quill stroke: 120 mm
- Speed range: 105–2900 min⁻¹
- Column diameter: 100 mm
- Base: 570 × 340 mm
- T-slots: 14 mm
Different types of bench drills
Bench drills come in several variants, each suitable for different types of work and users.
1. Compact hobby models
These machines are ideal for DIY projects and smaller workshops. They are space-saving, easy to use and handle most wood and plastic work. They usually have lower power but are affordable and reliable.
2. Mid-range models
Mid-range machines offer more power and precision and can handle both wood and metal. They often have multiple speed levels, better adjustment options and a more stable drill table. This type is popular among dedicated hobbyists and small workshops.
3. Professional pillar drills
The most advanced models are designed for continuous operation and high precision. They have powerful motors, large stroke lengths and precise adjustment systems. These machines are often used in metal workshops and production environments where accuracy and durability are crucial.
4. Magnetic and special-purpose drills
For work on large metal parts or steel structures, there are magnetic drills that can be attached directly to the surface. In addition, there are special-purpose machines with automatic feed or digital depth display that offer extra precision for demanding tasks.
Different brands of bench drills
The market for bench drills includes many manufacturers, each with their own focus and strengths.
Bosch
Bosch offers both hobby and professional models with a focus on user-friendliness and precision. Their machines are known for solid build quality and reliable motors.
Einhell
Einhell produces affordable bench drills that are well suited for the home workshop. They combine simple operation with good functionality and are a popular choice for home use.
Scheppach
Scheppach has a wide range of bench drills, from compact models to powerful pillar machines. The brand is known for good value for money and robust construction.
Metabo
Metabo focuses on professional users and offers machines with high precision, powerful motors and long service life. Many models feature electronic speed control and advanced safety functions.
Holzmann
Holzmann is an Austrian brand that manufactures machines for both hobby and industrial use. Their bench drills are characterised by powerful motors and a solid design suitable for demanding tasks.
Frequently asked questions
What can a bench drill be used for?
A bench drill is used for precision drilling in wood, metal and plastic. It ensures that the hole is drilled straight and at the desired angle, which is difficult to achieve with a hand drill.
How large should a bench drill be?
That depends on the materials and workpiece sizes you work with. For small projects, a compact model is often sufficient, while larger workpieces require a machine with a higher column and longer stroke.
How do you maintain a bench drill?
Keep the machine free of dust and chips, lubricate moving parts regularly and check belts and bearings for wear. Also make sure that the drill chuck is tight and clean.
Can a bench drill drill into metal?
Yes, most models can drill into metal as long as you use the right drill bit and appropriate speed. For harder metals, you should choose a machine with high motor power and low speed.
Is a bench drill safe to use?
Yes, if you follow basic safety rules. Always wear safety glasses, secure the workpiece firmly and avoid loose clothing. Many machines also have a safety cover and an emergency stop switch.
